IBMX3250 M3 1U高机架式服务器，搭载4C的英特尔至强3400系列处理，主频可达3.0GHz， 内存容量可达32GB，硬盘容量可以达到4TB，可以上2块3.5英寸的硬盘或4块2.5的硬盘，中规中矩的一款服务器，欲了解更多X3250系列的服务器的更多信息，欢迎咨询广州鑫瑞信息
| IBM服务器 X3250M3整机信息 | |
| 名称 | IBM System x3250 M3 |
| 型号 | 42,514,252 |
| 品牌 | IBM |
| 类型 | PC服务器 |
| CPU信息 | 英特尔至强3400系列（四核）（最高3.06GHz/8MB/1333MHz）或者英特尔赛扬、奔腾或酷睿i3（双核）（最高3.2GHz/4MB/1333MHz） |
| CPU类型 | 英特尔至强3400系列或者赛扬、奔腾或酷睿i3双核处理器 |
| CPU插槽数 | 1 |
| CPU激活 | 不需要激活 |
| 机架类型 | 机架式 |
| 机架空间 | |
| 硬盘信息 | 4.0TB SATA 器设备。或2.4TB SAS可选的光盘驱动。 |
| 最大硬盘数量 | 2 个 3.5 英寸易插拔 SATA 或 3.5 英寸热插拔 SAS/SATA，或者 4 个 2.5 英寸热插拔 SAS 硬盘驱动器 |
| 内存提示 | ECC |
| 支持内存容量范围 | 最高32GB DDR-3ECC 内存，高达1333MHz；1GB、2GB 和4GB UDIMM；1GB、2GB、4GB 和8GB RDIMM. |
| 内存插槽数量 | 6 |
| 内存是否需要激活 | 不需要激活 |
| 电源描述 | 351W |
| 单机电源数量 | 1 |
| 介质托架 | SATA Combo |
| 适配器插槽 | 2 个 PCIe x8 第二代，专用 PCIe x4 用于 RAID-0、-1，可选 PCI-X（CTO 或仅限特殊报价）。 |
| 端口 | 7 个 USB、2 个以太网、1 个串行和视频接口 |
| 发布日期 | |
| 下架日期 | 2011/2/28 |
| 服务截止期 | |
| 操作系统 | Microsoft Windows Server 2008STD、EE、R2/Microsoft Windows Server 2008x64STD、EE、DC/Windows Small Business Server2008、RedHat Linux、SUSE Linux |
| 产品尺寸 | 43×440×559mm |
| 产品重量 | 最大12.7kg |
IBM X3250 M5服务器上的可选配件参数详情列表
| 配件信息 | ||
| FC号 | PN号 | 描述 |
| CPU | ||
| 4510 | 46C6773 | Intel Xeon X3470 2.93GHz/1333MHz-8MB 4C |
| 5843 | 49Y4655 | Intel Xeon X3460 2.8GHz/1333MHz-8MB 4C, Models support 4251-62Y, 4252-62Y |
| 5845 | 49Y4603 | Intel Xeon X3450 2.67GHz/1333MHz-8MB 4C, Models support 4251-52Y, 4252-52Y, E1Y, E4Y |
| 5846 | 49Y4604 | Intel Xeon X3440 2.53GHz/1333MHz-8MB 4C, Models support 4251-42Y, 4252-42Y, E3Y |
| 5848 | 49Y4602 | Intel Xeon X3430 2.4GHz/1333MHz-8MB 4C, Models support 4251-C2Y, 4252-C2Y |
| 6475 | 69Y4580 | Intel Core i3-530 2.93 GHz 2C 4MB cache1333MHz 73W |
| 6476 | 69Y4581 | Intel Pentium G6950 2.8GHz 2C 3MB cache 1333MHz 73W, Models support 4251-A2Y, 4252-A2Y |
| 6477 | 69Y4582 | Intel Core-i3 540 3.06GHz 2C 4MB cache1333MHz 73W, Models support 4251-B2Y, 4252-B2Y |
| 6478 | 69Y4583 | Intel Xeon L3406 2.26GHz 2C 4MB cache 1066MHz 30W |
| 6479 | 69Y4584 | Intel Core-i3 550 3.2GHz 2C 4MB cache1333MHz 73W |
| 6480 | 69Y4585 | Intel Xeon x3480 3.06GHz 4C 8MB cache1333MHz 95W |
| A0QR | 69Y5280 | Intel Celeron G1101 2.26GHz 2C 2MB cache 1066 MHz 73W |
| 内存 | ||
| 1701 | 46C7444/46C7448 | 4GB (1x4GB, Quad Rankx8) PC3-8500 CL7 ECC DDR3 1066MHz LP RDIMM |
| 1706 | 46C7476/46C7482 | 8GB (1x8GB, Quad Rankx8) PC3-8500 CL7 ECC DDR3 1066MHz LP RDIMM |
| 1712 | 44T1587/44T1592 | 2GB (1x2GB, 1Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333MHz LP RDIMM |
| 1713 | 44T1597/44T1599 | 4GB (1x4GB, Dual Rankx8) PC3-10600 CL9 ECC DDR3 1333MHz LP RDIMM |
| 1912 | 44T1567/44T1571 | 4GB (1x4GB, Dual Rankx8) PC3-10600 CL9 ECC DDR3 1333MHz LP UDIMM |
| 1913 | 44T1566/44T1570 | 2GB (1x2GB, 1Rx8, 1.5V) PC3-10600 CL9 ECC DDR3 1333MHz LP UDIMM |
| 1914 | 44T1565/44T1569 | 2GB (1x2GB, 2Rx8, 1.5V) PC3-10600 ECC DDR3 1333Mhz LP UDIMM |
| 1915 | 44T1564/44T1568 | 1GB (1x1GB, Single Rankx8) PC3-10600 CL9 ECC DDR3 1333MHz LP UDIMM |
| 3963 | 44T1470/44T1480/44T1490 | 1GB (1x1GB, Single Rankx8) PC3-10600 CL9 ECC DDR3-1333 LP RDIMM |
| 3964 | 44T1471/44T1481/44T1491 | 2GB (1x2GB, Dual Rank x8) PC3-10600 CL9 ECC DDR3-1333 LP RDIMM |
| 硬盘 | ||
| 43W7535 | IBM 73 GB 10K SAS 2.5" SFF Slim-HS HDD | |
| 81Y9690 | IBM 1TB 7.2K 6Gbps NL SAS 2.5" SFF HS HDD SFF | |
| 5151 | 39M4527/39M4526 | IBM 250GB 7200 RPM 3.5" Hot-Swap SATA II |
| 5162 | 39R7350/40K1076/40K1044 | 146GB 15K 3.5" Hot-Swap SAS |
| 5196 | 39M4531/39M4530/39M4533 | IBM 500GB 7200 RPM 3.5" Hot-Swap SATA II |
| 5288 | 39M4515/39M4514 | 500GB 7200 RPM 3.5" Simple-Swap SATA II |
| 5292 | 39M4509/39M4508 | IBM 250GB 7200 RPM 3.5" Simple-Swap SATA II |
| 5311 | 44W2234/44W2235/44W2236 | IBM 300GB 15K 6Gbps SAS 3.5" Hot-Swap HDD |
| 5312 | 44W2241/44W2239/44W2240 | IBM 450GB 15K 6Gbps SAS 3.5" Hot-Swap HDD |
| 5313 | 44W2246/44W2244/44W2245 | IBM 600GB 15K 6Gbps SAS 3.5" Hot-Swap HDD |
| 5405 | 42D0749/42D0747 | IBM 160GB 7200 SATA 2.5" SFF Slim-HS HDD |
| 5409 | 42D0709/42D0707 | IBM 500GB 7200 6Gbps NL SAS 2.5" SFF Slim-HS HDD SFF |
| 5412 | 44W2296/44W2294 | IBM 146GB 15K 6Gbps SAS 2.5" SFF Slim-HS SED SFF |
| 5413 | 44W2266/44W2264 | IBM 300GB 10K 6Gbps SAS 2.5" SFF Slim-HS SED SFF |
| 5415 | 42D0784/42D0782 | IBM 2TB 7200 Nl SATA 3.5" HS HDD |
| 5416 | 42D0789/42D0787 | IBM 2TB 7200 Nl SATA 3.5" SS HDD |
| 5417 | 42D0769/42D0767 | IBM 2TB 7.2K 6Gbps NL SAS 3.5" HS HDD |
| 5418 | 42D0779/42D0777 | IBM 1TB 7.2K 6Gbps NL SAS 3.5" HS HDD |
| 5433 | 49Y2005/49Y2003 | IBM 600GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD SFF |
| 5522 | 42D0674/42D0672 | IBM 73GB 15K 6Gbps SAS 2.5" SFF Slim-HS HDD |
| 5530 | 43W7577/43W7576 | 750GB 3.5" Hot-Swap SATA II |
| 5531 | 43W7573/43W7572 | 750GB 7200 RPM 3.5" Simple-Swap SATA II |
| 5536 | 42D0679/42D0677 | IBM 146GB 15K 6Gbps SAS 2.5" SFF Slim-HS HDD SFF |
| 5537 | 42D0634/42D0632/42D0633 | IBM 146GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD |
| 5559 | 43W7623/43W7622/43W7625 | IBM 1TB 7.2K SATA 3.5" Simple-Swap HDD |
| 5560 | 43W7627/43W7626 | IBM 1TB 7200 SATA 3.5 HS HDD |
| 5599 | 42D0639/42D0637 | IBM 300GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD SFF |
| A0WU | 43W7751/43W7750 | IBM 250GB SATA 3.5 SS HDD |
| A0WV | 43W7755/43W7754 | IBM 250GB SATA 3.5 HS HDD |
| A1AV | 81Y9730/81Y9732 | IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD SFF |
| A1NX | 81Y9724/81Y9722 | IBM 250GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD |
| A1NZ | 81Y9728/81Y9726 | IBM 500GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD |
| A27Z | 81Y9776/81Y9774 | IBM 3TB 7.2K 6Gbps NL SATA 3.5" HS HDD |
| A280 | 81Y9780/81Y9778 | IBM 3TB 7.2K 6Gbps NL SATA 3.5" SS HDD |
| A281 | 81Y9760/81Y9758 | IBM 3TB 7.2K 6Gbps NL SAS 3.5" HS HDD |
| A282 | 81Y9652/81Y9650 | IBM 900GB 10K 6Gbps SAS 2.5" SFF HS HDD |
| A283 | 81Y9672/81Y9670 | IBM 300GB 15K 6Gbps SAS 2.5" SFF HS HDD |
| A2FN | 43W7719/43W7718 | IBM 200GB SATA 2.5" MLC HS SSd SFF |
| A2U3 | 90Y8645/90Y8643 | IBM 256GB SATA 2.5" MLC HS Entry SSD SFF |
| A2U4 | 90Y8650/90Y8648 | IBM 128GB SATA 2.5" MLC HS Entry SSD SFF |
| RAID卡 | ||
| 93 | 46M0850/46M0829 | ServeRAID M5015 SAS/SATA Controller (Battery not included) |
| 94 | 46M0853/46M0830 | ServeRAID M5025 SAS/SATA Controller - PCI-E x8 |
| 95 | 46M0862/46M0831 | ServeRAID M1015 SAS/SATA Controller |
| 3559 | 43W4340/44E8825/43W4339 | ServeRAID-MR10is VAULT SAS/SATA Controller |
| 3571 | 43W4298/43W4296 | ServeRAID-MR10i SAS/SATA Controller - PCI-E x8 |
| 3584 | 44E8839/44E8695/44E8696 | ServeRAID-MR10M SAS/SATA Controller with Remote Battery Kit |
| 3877 | 46M0922/46M0916/46M0918 | ServeRAID M5014 SAS/SATA Controller (Battery not included) |
| 9742 | 49Y4738/49Y4731 | ServeRAID-BR10il SAS/SATA Controller v2 - PCI-E x4 |
| 网卡 | ||
| 1485 | 39Y6071/39Y6066 | NetXtreme II 1000 Express G Ethernet Adapter- PCIe |
| 1637 | 42C1823/42C1820/42C1822 | Brocade 10Gb CNA for IBM System x PCIe 8x |
| 2944 | 39Y6129/39Y6126 | PRO/1000 PT Dual Port Server Adapter by Intel |
| 2974 | 39Y6138/39Y6139/39Y6136 | PRO/1000 PT Quad Port Server Adapter |
| 2995 | 42C1783/42C1780/49Y4205 | NetXtreme II 1000 Express Dual Port Ethernet |
| 5751 | 42C1800/42C1802/42C1803 | QLogic 10Gb CNA for IBM System x PCI-E |
| 5766 | 49Y4223/49Y4220 | NetXtreme II 1000 Express Quad Port Ethernet Adapter |
| 5767 | 49Y4233/49Y4230 | Intel Ethernet Dual Port Server Adapter I340- T2 for IBM System x |
| 5768 | 49Y4243/49Y4240 | Intel Ethernet Quad Port Server Adapter I340- T4 for IBM System x |
| A18Y | 49Y7913/49Y7910 | Broadcom NetXtreme II Dual Port 10GBaseT Adapter for IBM System x |
| A1M4 | 81Y9991/81Y9990 | Mellanox ConnectX-2 Dual Port 10GbE Adapter for IBM System x |
| A2EC | 49Y7963/49Y7960 | Intel x520 Dual Port 10GbE SFP+ Adapter for IBM System x |
| A2V3 | 90Y9353/90Y9352 | Broadcom NetXtreme I Quad Port GbE Adapter for IBM System x |
| A2V4 | 90Y9371/90Y9370 | Broadcom NetXtreme I Dual Port GbE Adapter for IBM System x |
| WZ80 | 59Y8022 | PRO/1000 PT Quad Port Server Adapter |
| 适配卡 | ||
| 40K2599 | SAS Enclosure Adapter Kit | |
| 69 | 49Y4217/49Y4216/42C1819 | Brocade 10Gb SFP+ SR Optical Transceiver |
| 2975 | 42C1752/42C1753/42C1750 | PRO/1000 PF Server Adapter Half x4 PCIe by intel. |
| 2976 | 39Y6148/39Y6149/39Y6146 | QLogic iSCSI Single Port PCIe HBA for IBM System x |
| 2977 | 42C1772/42C1773/42C1770 | QLogic iSCSI Dual Port PCIe HBA for IBM System x |
| 3583 | 44E8702/44E8700 | IBM 3Gb SAS HBA Controller v2 - PCI-E x8 1,2 N 2 |
| 5982 | 68Y7355/46M0907 | IBM 6Gb SAS HBA |
| A1NQ | 81Y9998 | 2U Bracket for Mellanox ConnectX-2 Dual Port 10GbE Adapter |
| A1XL | 81Y4493/81Y4492 | ServeRAID H1110 SAS/SATA Controller for IBM System x |
| 光纤卡 | ||
| 3578 | 42D0502/42D0501/42D0507 | QLogic 8Gb FC Single-port HBA for IBM System x |
| 3579 | 42D0511/42D0510/42D0516 | QLogic 8Gb FC Dual-port HBA for IBM System x |
| 3580 | 42D0486/42D0485/42D0491 | Emulex 8Gb FC Single-port HBA for IBM System x |
| 3581 | 42D0495/42D0494/42D0500 | Emulex 8Gb FC Dual-port HBA for IBM System x |
| 3589 | 46M6051/46M6049/42D0549/42D6049/46M6061 | Brocade 8Gb FC Single-port HBA for IBM System x |
| 3591 | 46M6052/46M6050/46M6062 | Brocade 8Gb FC Dual-port HBA for IBM System x |
| 3885 | 59Y1988/59Y1987/59Y1992 | Brocade 4Gb FC Single-port HBA for IBM System x |
| 3886 | 59Y1994/59Y1993/59Y1998 | Brocade 4Gb FC Dual-port HBA for IBM System x |
| 电源 | ||
| 21301RX | IBM UPS3000 LV | |
| 21302RX | IBM UPS3000 HV | |
| 21303RX | IBM UPS 7500Xhv | |
| 21304RX | IBM UPS 10000Xhv | |
| 24195KX | IBM UPS5000 HV | |
| 53953AX | IBM 3000VA LCD 3U Rack UPS (100V/120V) | |
| 53953JX | IBM 3000VA LCD 3U Rack UPS (200V/208V) | |
| 53956AX | IBM 6000VA LCD 4U Rack UPS (200V/208V) | |
| 53956KX | IBM 6000VA LCD 4U Rack UPS (230V) | |
| 53959KX | IBM 11000VA LCD 5U Rack UPS (200V/208V/230V) | |
| 电池 | ||
| 5744 | 46M0857/46M0917 | ServeRAID M5000 Series Battery Assembly |
| 5864 | 44E8840/44E8826 | ServeRAID-MR10i Li-Ion Battery |
| 光驱 | ||
| 4161 | 44W3251/46M0901 | IBM UltraSlim Enhanced SATA DVD-ROM |
| 4162 | 44W3252 | UltraSlim Enhanced SATA CD-RW / DVD-ROM Combo |
| 4163 | 44W3253/46M0902 | IBM UltraSlim Enhanced SATA Multi-Burner |
| 磁带机 | ||
| 3628L3X | IBM Half High LTO Gen 3 External SAS Tape Drive | |
| 3628L4X | IBM Half High LTO Gen 4 External SAS Tape Drive | |
| 3628L5X | IBM Half High LTO Gen 5 External SAS Tape Drive | |
| 87651NX | 1U Tape Enclosure, No Power Cord | |
| 87651UX | 1U Tape Drive Enclosure | |
| 8767HHX | Half High Tape Drive Enclosure | |
| 8767HNX | HH Tape Enclosure, No Power Cord | |
| 5345 | 49Y9902/49Y9898 | IBM Half High LTO Gen 5 Internal SAS Tape Drive |
| 5393 | 43W8490/43W8478 | IBM Half High LTO Gen 3 SAS Tape Drive |
| 5395 | 43W8492/39M5636 | IBM DDS Gen 6 USB Tape Drive |
| 5397 | 44E8897/44E8895 | IBM Half-high LTO Gen 4 SAS Tape Drive |
| 5711 | 49Y9880/46C5399 | IBM DDS Generation 5 USB Tape Drive |
| 线缆 | ||
| 31R3132 | IBM 3M Console Switch Cable (USB) | |
| 3701 | 40K9805 | 5m LC-LC Fiber Cable (networking) |
| 3702 | 40K9806 | 25m LC-LC Fiber Cable (networking) |
| 3707 | 42C2061/39R6531 | IBM 3M SAS Cable |
| 3708 | 42C2060/39R6529 | IBM 1M SAS Cable |
| 3793 | 40K8960 | 3m Yellow Cat5e Cable |
| 3795 | 40K8941 | 25m Yellow Cat5e Cable |
| 3796 | 40K8963 | 0.6m Green Cat5e Cable |
| 3797 | 40K5627 | 1.5m Green Cat5e Cable |
| 3798 | 40K5791 | 3m Green Cat5e Cable |
| 3799 | 40K5792 | 10m Green Cat5e Cable |
| 3800 | 40K8868 | 25m Green Cat5e Cable |
| 3801 | 40K8949 | 0.6m Blue Cat5e Cable |
| 3802 | 40K5564 | 1.5m Blue Cat5e Cable |
| 3803 | 40K8936 | 3m Blue Cat5e Cable |
| 3804 | 40K8926 | 10m Blue Cat5e Cable |
| 3805 | 40K8929 | 25m Blue Cat5e Cable |
| 6316 | 39Y5532 | Rack power cable - 2.0m, 125-250V, C13 to IEC 320-C14 (WW) |
| A1RF | 46M2590 | 10A/250V C13 to NEMA 6-15P 2.8m line cord |
| 其它 | ||
| 14102RX | IBM 25RU standard rack | |
| 14104RX | IBM 42U S2 standard rack | |
| 172317X | 1U 17in Flat Panel Console Kit | |
| 172319X | 1U 19in Flat Panel Console Kit | |
| 17231RX | IBM 1U 17" Flat Panel console Kit w/ Optical Drive Bay | |
| 17233RX | IBM 1U 15" Flat Panel Console Kit | |
| 172621X | IBM System Storage DS3200 | |
| 172622X | IBM System Storage DS3200 | |
| 172631X | IBM System Storage DS3300 iSCSI Single Controller Model | |
| 172632X | IBM System Storage DS3300 iSCSI Dual Controller Model | |
| 172641X | IBM System Storage DS3400 | |
| 172642X | IBM System Storage DS3400 | |
| 172701X | IBM System Storage EXP3000 | |
| 17351GX | IBM Local 2x8 Console Manager (LCM2) | |
| 17352GX | IBM Global 2x16 Console Mngr(GCM2) | |
| 17353LX | IBM 1 x 8 Console Switch | |
| 17354LX | IBM 2 x 16 Console Switch | |
| 1746A2D | IBM System Storage DS3512 Express Dual Controller Storage System | |
| 1746A2S | IBM System Storage DS3512 Express Single Controller Storage System | |
| 1746A4D | IBM System Storage DS3524 Express Dual Controller Storage System | |
| 1746A4S | IBM System Storage DS3524 Express Single Controller Storage System | |
| 174712X | IBM System Storage EXP2512 Express Storage Enclosure | |
| 174724X | IBM System Storage EXP2524 Express Storage Enclosure | |
| 1754A1X | IBM Local 1X8 Console Manager | |
| 1754A2X | IBM Local 2X16 Console Manager | |
| 1754D1X | IBM Global 2X2X16 Console Manager | |
| 1754D2X | IBM Global 4X2X32 Console Manager | |
| 39M2816 | IBM Dpi C13 PDU+ | |
| 39M2817 | iDPx Three-phase 60A/208V Enterprise C13 PDU+ | |
| 39R6475 | 4Gb Short Wave SFP | |
| 39Y8905 | DPI 100-127v PDU with Fixed Nema L5-15P line cord | |
| 39Y8923 | IBM Enterprise C19 3 phase PDU (60a) | |
| 39Y8938 | DPI 30amp/125V Front-end PDU with NEMA L5-30P | |
| 39Y8939 | DPI 30amp/250V Front-end PDU with NEMA L6-30P | |
| 39Y8940 | DPI 60amp/250V Front-end PDU with IEC 309 2P+Gnd connector | |
| 39Y8941 | IBM Enterprise C13 PDU | |
| 39Y8948 | IBM Enterprise C19 PDU | |
| 39Y8951 | DPI Universal Rack PDU with Nema L5-20P and L6-20P | |
| 40K5372 | IBM Keyboard w/ Integrated Pointing Device USB - US English 103P | |
| 44E8869 | USB Enclosure Adapter Kit | |
| 46M4002 | IBM 1U 9 C19/3 C13 Switched and Monitored DPI PDU | |
| 46M4003 | IBM 1U 9 C19/3 C13 Switched and Monitored 60A 3 Phase PDU | |
| 46M4004 | IBM 1U 12 C13 Switched and Monitored DPI PDU | |
| 46M4005 | IBM 1U 12 C13 Switched and Monitored 60A 3 Phase PDU | |
| 46M4110 | IBM LCD UPS Network Management Card | |
| 46M4116 | IBM 0U 24 C13 Switched and Monitored 30A PDU | |
| 46M4125 | IBM 0U 24 C13 30A 3 Phase PDU | |
| 46M4128 | IBM 0U 24 C13 30A PDU | |
| 46M4134 | IBM 0U 12 C19/12 C13 Switched and Monitored 50A 3 Phase PDU | |
| 46M4140 | IBM 0U 12 C19/12 C13 50A 3 Phase PDU | |
| 46M4167 | 1U Switch. and Monit. PDU 9 C19 / 3 C13 3ph 30A fixed 4.3m L21-30P. | |
| 71762MX | IBM Ultra Density Enterprise C19/C13 PDU+ Module | |
| 71762NX | IBM Ultra Density Enterprise C19/C13 PDU Module | |
| 71763MU | IBM Ultra Density Enterprise C19/C13 PDU+ 60A/208V/3ph | |
| 71763NU | IBM Ultra Density Enterprise C19/C13 PDU 60A/208V/3ph | |
| 93072PX | IBM S2 25U Static Base Cabinet | |
| 93072RX | IBM 25U S2 standard rack | |
| 93074RX | NetBAY S2 42U Standard Rack Cabinet | |
| 93074XX | IBM 42U S2 expansion rack | |
| 93084EX | IBM 42U Enterprise Expansion Rack | |
| 93084PX | IBM 42U Enterprise Rack | |
| 93604EX | IBM 42U 1200mm Deep Dynamic Expansion Rack | |
| 93604PX | IBM 42U 1200mm Deep Dynamic Rack | |
| 93614EX | IBM 42U 1200mm Deep Static Expansion Rack | |
| 93614PX | IBM 42U 1200mm Deep Static Rack | |
| 93624EX | IBM 47U 1200mm Deep Static Expansion Rack | |
| 93624PX | IBM 47U 1200mm Deep Static Rack | |
| 99564RX | IBM S2 42U Dynamic Standard Rack Cabinet | |
| 99564XX | IBM S2 42U Dynamic Expansion Rack Cabinet | |
| 64 | 49Y4219/49Y4218 | QLogic 10Gb SFP+ SR Optical Transceiver |
| 1776 | 46M4989/41Y8278 | IBM USB Memory Key for VMware ESXi 47 |
| 3033 | IBM USB Memory Key for VMware ESXi 4.1 | |
| 3756 | 39Y7960/39M2895 | IBM USB Conversion Option Pack |
| 3757 | 39Y8072/43V6147 | IBM Single Cable USB Conversion Option (UCO) |
| 3758 | 39Y7957/39M2894 | Virtual Media Conversion Option |
| 3876 | 46M0914/46M0912 | IBM 6Gb Performance Optimized HBA |
| 5106 | 46M0932/46M0930 | ServeRAID M5000 Series Advance Feature Key |
| 5340 | 69Y2045/46M5382 | IBM Serial Conversion Option (SCO) |
| 5341 | 69Y2046/46M5383 | IBM Virtual Media Conversion Option Gen2 (VCO2) |
| 5698 | 49Y4611 | Base Hardware/High Efficiency PSU (Quad-core processor recommended) |
| 5699 | 49Y4610 | Base Hardware/Fixed PSU (Quad-core processor recommended) |
| 5715 | 49Y4278 | Emulex VFA II FCoE/iSCSI License for IBM System x |
| 5749 | 49Y4253/49Y4250 | Emulex 10GbE Virtual Fabric Adapter |
| 5891 | 43V6991/46C7527 | IBM Virtual Media Key For Entry Systems Other I/O |
| 8750 | 40K9490/40K9584 | IBM Preferred Pro Keyboard USB - US English 103P |
| 8912 | 40K9491/40K9200 | IBM 2 Button Optical Wheel Mouse - Black - USB |
| 9749 | 46M0865/46M0832 | ServeRAID M1000 Series Advance Feature |
| A10C | 81Y4428/81Y4426 | ServeRAID M5000 Series Performance Accelerator Key |
| A18Z | 49Y7953/49Y7950 | Intel x520 Dual Port 10GbE SFP+ Adapter for |
| A2VC | 94Y9770/41Y8300 | IBM USB Memory Key for VMWare ESXi 5.0 |
