HP/惠普 DL320 G5，1U机架式服务器，标配1颗CPU， 8GB内存，是一款入门级简单的服务器，欲了解更多的DL320系列服务器整机及相关配件，请联系广州鑫瑞信息
| 名称 | HP ProLiant DL320 G5p Server series |
| 型号 | |
| 品牌 | HP |
| 类型 | PC服务器 |
| CPU信息 | 1 个处理器 |
| CPU类型 | 英特尔 至强 |
| CPU插槽数 | 1 |
| CPU激活 | 不需要激活 |
| 机架类型 | 机架式 |
| 机架空间 | 1U |
| 硬盘信息 | 最大内部存储容量及类型：SATA 3.0TB 4 x 750GB SATA；SAS 1.2TB 4 x 300GB SAS |
| 最大硬盘数量 | 4 |
| 内存提示 | 内存类型 PC2-6400 (800MHz)无缓冲ECC DDR2 SDRAM可选交叉存取(可成对安装DIMM 时) |
| 支持内存容量范围 | 最大内存 8 GB |
| 内存插槽数量 | 4 |
| 内存是否需要激活 | 不需要激活 |
| 电源描述 | 自适应400瓦PFC电源，符合CE 标志标准 |
| 单机电源数量 | 1 |
| 介质托架 | DVD-RW光驱(可选)；DVD-ROM 光驱(可选) |
| 适配器插槽 | Two total slots:Full length PCI Express x8 slot (x8 connector). Can be replaced with a full-length 64-bit /133MHz PCI-X slot. |
| 端口 | USB 2.0 5个(正面2个，内置1个(可选)，背面2个)；RJ-45网络接口2个(网卡1共享iLO 2端口)。 |
| 发布日期 | |
| 下架日期 | 2009/9/30 |
| 服务截止期 | |
| 操作系统 | Microsoft Windows Server 2003 (web版、标准版和企业版；标准版和企业版支持64位扩展)；Microsoft Windows Server 2008；Red Hat Enterprise Linux；SUSE Linux Enterprise Server。 |
| 产品尺寸 | (高 x 宽 x 长) (带支架) 4.32 x 44.80 x 68.19厘米(1.70 x 17.64 x 26.85英寸) |
| 产品重量 | 最大(已安装的 4个硬盘驱动器、电源和处理器) 15.20千克(33.50磅) |
HP/惠普 ProLiant DL320 G5服务器可选配件参数信息>>>>>>>>
| 配件信息 | ||
| FC号 | PN号 | 描述 |
| CPU | ||
| 450125-L21 | Intel® Celeron 420 processor FIO Kit | |
| 450141-L21 | Quad-Core Intel® Xeon® X3220 processor FIO Kit | |
| 450143-L21 | Dual-Core Intel® Xeon® 3065 processor FIO Kit | |
| 455031-L21 | Quad-Core Intel® Xeon® X3210 processor FIO Kit | |
| 455035-L21 | Dual-Core Intel® Pentium E2160 Processor FIO Kit | |
| 463432-L21 | Quad-Core Intel® Xeon® X3350 processor FIO Kit | |
| 463434-L21 | Quad-Core Intel® Xeon® X3320 processor FIO Kit | |
| 463436-L21 | Dual-Core Intel® Xeon® E3110 processor FIO Kit | |
| 468963-L21 | Intel® Celeron 440 processor FIO Kit | |
| 489909-L21 | Quad-Core Intel® Xeon® X3360 processor FIO Kit | |
| 493241-L21 | Dual-Core Intel® Xeon® E3120 processor FIO Kit | |
| 493247-L21 | Quad-Core Intel® Xeon® X3370 processor FIO Kit | |
| 系统板 | ||
| 450341-B21 | HP DL320G5p PCI-X Riser Board Kit | |
| 内存 | ||
| 351580-B21 | 128MB BBWC for SA641/642 | |
| 405148-B21 | 512 MB Battery-backed write cache upgrade | |
| 450258-B21 | 512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB) | |
| 450259-B21 | 1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB) | |
| 450260-B21 | 2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB) | |
| 硬盘 | ||
| 349238-B21 | 160.0GB 1.5Gbps Serial ATA (SATA) hot-plug hard drive - 7,200 RPM, 3.5-inch form factor | |
| 349239-B21 | 250.0GB 1.5Gbps Serial ATA (SATA) hot-plug hard drive - 7,200 RPM, 3.5-inch form factor | |
| 384852-B21 | HP 72.0GB hot-plug Serial Attached SCSI (SAS) hard drive - 15,000RPM, 3.5-inch form factor | |
| 384854-B21 | HP 146.0GB hot-plug Serial Attached SCSI (SAS) hard drive - 15,000RPM, 3.5-inch form factor | |
| 395473-B21 | HP 500GB 1.5Gbps Serial ATA (SATA) hot-plug hard drive - 7,200 RPM, 3.5-inch form factor | |
| 416127-B21 | HP 300.0GB 3.0Gbps Serial Attached SCSI (SAS) hot-plug hard drive - 15,000 RPM, 3.5-inch form factor | |
| 432341-B21 | HP 750.0GB hot-plug Serial ATA (SATA) hard drive - 7,200 RPM, 1.5GB/sec transfer rate, Native Command Queing (NCQ), 3.5-inch form factor | |
| 454146-B21 | HP 1TB 3G 7,200 RPM Hot-swap Midline (MDL) Serial ATA (SATA) 1-year Warranty 3.5-inch Hard Disk Drive | |
| 454232-B21 | HP 450GB 3Gb/s Serial Attached SCSI (SAS) hard drive - 15,000 RPM, 3.5-inch form factor | |
| 458926-B21 | HP 250GB 3Gb/s SATA hard disk drive - 7,200 RPM, 3.5-inch form factor | |
| 458928-B21 | HP 500GB 3Gb/s SATA hard drive disk - 7,200 RPM, 3.5-inch form factor | |
| 458930-B21 | HP 750GB 3Gb/s SATA hard drive disk - 7,200 RPM, 3.5-inch form factor | |
| 458945-B21 | HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive | |
| 459508-B21 | HP 400GB 3Gb/s Serial Attached SCSI (SAS) hard drive disk- 10,000 RPM, 3.5-inch form factor | |
| 461135-B21 | HP 750GB 3Gb/s Serial Attached SCSI (SAS) hard drive - 7,200 RPM, 3.5-inch form factor | |
| 461137-B21 | HP 1TB 3Gb/s Serial Attached SCSI (SAS) hard drive - 7,200 RPM, 3.5-inch form factor | |
| RAID卡 | ||
| 347786-B21 | HP 8 Internal Port SAS 64/133 PCI-X RAID Host Bus Adapter | |
| SCSI卡 | ||
| AH627A | HP U320e SCSI Dual Channel Host Bus Adapter | |
| 网卡 | ||
| 394795-B21 | HP NC380T PCI-Express dual-port multifunction gigabit server adapter | |
| 434905-B21 | HP NC110T single-port copper single-lane (x1) PCI-Express 10/100/1000 Base-T gigabit server adapter board | |
| 435508-B21 | HP NC364T PCI Express Quad Port Gigabit Server Adapter | |
| 适配卡 | ||
| 262587-B21 | PS/2 adapter - Allows connection to CAT5 Server Console Switch KVM or IP Console Switch KVM using Category 5 (CAT5) cable - Package contains one adapter | |
| 262588-B21 | KVM Cat5 USB interface adapter - Includes one adapter | |
| 332815-B21 | PS/2 adapter - Allows connection to CAT5 Server Console Switch KVM or IP Console Switch KVM using Category 5 (CAT5) cable - Package contains eight adapters | |
| 374654-B21 | 64-Bit/133-MHz Single Channel Ultra320 SCSI Host Bus Adapter (HBA) G2 - PCI-X interface, 320MBps data transfer rate - One (1) channel, supports up to 14 storage devices | |
| 394791-B21 | HP NC373T PCI Express Multifunction Gigabit Server Adapter | |
| 394793-B21 | HP NC373F PCI Express Multifunction Gigabit Server Adapter | |
| 412648-B21 | HP NC360T PCI Express Dual Port Gigabit Server Adapter | |
| 412911-B21 | HP SC11Xe Host Bus Adapter | |
| 416096-B21 | HP SC44Ge Host Bus Adapter | |
| 488765-B21 | HP SC08Ge Host Bus Adapter | |
| AF103A | HP CAT5 RJ45-DB9 DCE Female 8 Pack Serial Adapter | |
| AF110A | HP 1-pack PS/2 Virtual Media Interface Adapter | |
| AF604A | HP 1-pack PS/2 Virtual Media Interface Adapter | |
| 光纤卡 | ||
| A8002A | HP StorageWorks FC2142SR PCI Express 4Gb Host Bus Adapter | |
| A8003A | HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e Host Bus Adapter | |
| AE311A | HP StorageWorks FC1142 4Gb PCI-Express Host Bus Adapter | |
| AE312A | HP StorageWorks FC1242SR 4Gb PCIe dual-channel Host Bus Adapter | |
| AJ763A | HP StorageWorks 82E 8Gb Dual-port PCI Express Fiber Channel Host Bus Adapter | |
| AJ764A | HP StorageWorks 82Q 8Gb Dual Port PCIe Fiber Channel Host Bus Adapter | |
| AK344A | HP StorageWorks 81Q PCIe Fiber Channel Host Bus Adapter | |
| 电源 | ||
| AF414A | HP R3000 VA UPS, 2U, DTC, INTL | |
| AF416A | HP R5500 VA UPS, INTL | |
| AF422A | HP R3000 VA UPS, 2U, Low Voltage L5-30, NA | |
| AF423A | HP R3000 VA UPS, 2U, High Voltage L6-20, NA | |
| AF424A | HP R3000 VA UPS, 2U, High Voltage L6-20, JPN | |
| AF425A | HP R3000 VA UPS, 2U, Low Voltage L5-30, JPN | |
| AF444A | HP R3000v UPS | |
| AF446A | HP T750 G2 UPS, NA | |
| AF447A | HP T750 G2 UPS, INTL | |
| AF448A | HP T1000 G3 UPS, NA | |
| AF449A | HP T1000 G3 UPS, INTL | |
| AF450A | HP T1500 G3 UPS, NA | |
| AF451A | HP T1500 G3 UPS, INTL | |
| AF456A | HP T750J UPS, Japan | |
| AF457A | HP T1000J UPS, Japan | |
| AF458A | HP T1500J UPS, Japan | |
| 电池 | ||
| 383280-B21 | HP Smart Array Cache Battery Kit - For Smart Array P400 Controller only | |
| 光驱 | ||
| 481041-B21 | HP Slim SATA DVD-ROM Optical Drive | |
| 481043-B21 | HP Slim SATA DVDRW Optical Drive | |
| 481045-B21 | HP 9.5mm SATA DVD ROM Kit | |
| 481047-B21 | HP 9.5mm SATA DVD RW Kit | |
| 磁带机 | ||
| AG703A | HP StorageWorks 1U USB Rack-Mount Kit with one DAT 160 USB Tape Drive | |
| AH166A | HP 1/8 G2 Tape Autoloader Rack Kit | |
| AH558A | HP StorageWorks 1/8 G2 Ultrium 920 SAS Tape Autoloader | |
| AH559A | HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library | |
| AH560A | HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library | |
| AK377A | HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader | |
| AK378A | HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Drive Library | |
| AK380A | HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Drive Library | |
| DW085A | HP StorageWorks Ultrium 448 SAS Internal Tape Drive | |
| EH847A | HP StorageWorks Ultrium 920 SAS Internal Tape Drive | |
| 导轨 | ||
| AE459A | HP StorageWorks 1U SAS Rack Mount Kit - Supports up to two half-height tape drives and is compatible with the Ultrium 448 SAS and Ultrium 920 SAS tape drives | |
| 线缆 | ||
| 417836-B21 | Smart Array P400 battery attach cable kit - 61cm (24in) long | |
| 451363-B21 | HP Internal USB Cable Kit | |
| AF612A | HP 1x4 KVM Console 6ft USB Cable - Server console cable for USB Keyboard, Video, Mouse (KVM) - 1.82m (6ft) long - Two cables are included | |
| AF613A | HP 1x4 KVM Console 6ft USB Cable - Server console cable for USB Keyboard, Video, Mouse (KVM) - 1.82m (6ft) long - Two cables are included | |
| 其它 | ||
| 273914-B21 | Smart Array 6404/256 Controller | |
| 273915-B21 | Smart Array 6402/128 Controller | |
| 291967-B21 | Smart Array 642 Controller | |
| 292302-B22 | HP S10614 (14U) Rack Cabinet – Shock Pallet | |
| 302969-B21 | HP StorageWorks Modular Smart Array 30 | |
| 302970-B21 | HP StorageWorks Modular Smart Array 30 DB | |
| 358254-B21 | HP 5642 cabinet (Metallic Carbonite color) - 42U, 19-inch - Assembled and installed by the customer - Includes cover, side panels, two locking rear doors, leveling feet - Ships on a pallet | |
| 381513-B21 | HP Smart Array P800/512 BBWC Controller | |
| 401222-B21 | Serial/Parallel Port OPT KIT | |
| 405132-B21 | HP Smart Array P400/256MB Controller | |
| 411064-B21 | HP Smart Array P400/512MB Controller with BBWC | |
| 411508-B21 | HP Smart Array E200/128 BBWC Controller | |
| 418408-B21 | HP StorageWorks 60 Modular Smart Array | |
| 418800-B21 | HP StorageWorks 70 Modular Smart Array | |
| 435129-B21 | HP Smart Array E500/256MB Controller | |
| 436222-B21 | HP Insight Software Media Kit | |
| 442085-B21 | HP 1GB USB 2.0 Floppy Drive Key | |
| 445436-B21 | DL320G5p CTO (Configure-To-Order) Chassis | |
| 450343-B21 | DL320G5p iLO2 PORT OPT KIT | |
| 450434-B21 | DL1U 4 DRV CAGE FIO Kit | |
| 450436-B21 | DL1U 2 DRV CAGE FIO Kit | |
| 452130-B21 | NOTE: Any Smart Array Controller CTO purchase automatically includes the HP HBA SAS-SATA 4x1LN Cable Kit (452130-B21). | |
| 452148-B22 | HP Insight Control suite, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates | |
| 464422-B22 | HP Insight Control suite for Linux, Media pack (DVD) - No licenses included | |
| 464423-B22 | HP Insight Control suite for Linux, No Media, 1-Server license, including one year of 24x7 Technical Support and Updates | |
| AF001A | 10642 G2 (42U) Rack Cabinet - Pallet | |
| AF002A | 10642 G2 (42U) Rack Cabinet - Shock Pallet | |
| AF003A | 10642 G2 (42U) Rack Cabinet - Crated | |
| AF004A | 10642 G2 (42U) Rack Cabinet, with Extension - Shock Pallet | |
| AF011A | 10636 G2 (36U) Rack Cabinet - Pallet | |
| AF012A | 10636 G2 (36U) Rack Cabinet - Shock Pallet | |
| AF013A | 10636 G2 (36U) Rack Cabinet - Crated | |
| AF014A | 10636 G2 (36U) Rack Cabinet , with Extension - Shock Pallet | |
| AF021A | 10622 G2 (22U) Rack Cabinet - Pallet | |
| AF022A | 10622 G2 (22U) Rack Cabinet - Shock Pallet | |
| AF031A | 10647 G2 (47U) Rack Cabinet - Pallet | |
| AF041A | 10842 G2 (42U) 800mm Wide Rack Cabinet - Pallet | |
| AF042A | 10842 G2 (42U) 800mm Wide Rack Cabinet - Shock Pallet | |
| AF044A | 10647 G2 (47U) Rack Cabinet 1200mm Deep - Shock Pallet | |
| AF045A | 10647 G2 (47U) Rack Cabinet 1200mm Deep - Pallet | |
| AF101A | HP Serial Console Servers - 16 ports | |
| AF102A | HP Serial Console Servers - 48 ports | |
| AF418A | HP Rack Uninterruptible Power System R1500 G2 - 1U, 4.5cm (1.75in) high (International) | |
| AF419A | HP R1.5 VA 1U Uninterruptible Power System | |
| AF421A | HP R1.5 VA 1U Uninterruptible Power System - (Japan, Taiwan) | |
| AF426A | HP Rack Uninterruptible Power System R5500 (North America or Japan) | |
| AF601A | HP 2x1x16 IP Console Switch with USB/Virtual Media | |
| AF602A | HP 4x1x16 IP Console Switch with USB/Virtual Media | |
| AF611A | HP 1x4 USB/PS2 KVM console switch | |
| AF616A | HP Server Console 0x2x8 Port Analog Switch | |
| AF617A | HP Server Console 0x2x16 Port Analog Switch | |
| AG052A | HP TFT7600 Rackmount Keyboard and Monitor - Active Matrix Thin Film Transistor (TFT)7600 (United States) | |
| AG053A | TFT7600RKM UK | |
| AG054A | TFT7600RKM GR | |
| AG055A | TFT7600RKM FR | |
| AG056A | TFT7600RKM IT | |
| AG057A | TFT7600RKM SP | |
| AG058A | TFT7600RKM DEN | |
| AG059A | TFT7600RKM NOR | |
| AG060A | TFT7600RKM SE/FI | |
| AG061A | TFT7600 Rackmount Keyboard Monitor SWI | |
| AG062A | TFT7600RKM PORT | |
| AG063A | TFT7600RKM BEL | |
| AG064A | TFT7600RKM JPN2 | |
| AG065A | TFT7600RKM RUS | |
| AG066A | TFT7600RKM INTL | |
| AG072A | HP 1U rackmount keyboard - includes three button touch pad, 4 scroll keys, and Windows shortcut keys - has PS2 and USB connections includes USB port on the front of the keyboard for USB pass through | |
| AG073A | 1U Rackmount Keyboard with USB, UK | |
| AG074A | 1U Rackmount Keyboard with USB, GR | |
| AG075A | 1U Rackmount Keyboard with USB, FR | |
| AG076A | 1U Rackmount Keyboard with USB, ITL | |
| AG077A | 1U Rackmount Keyboard with USB, SP | |
| AG078A | 1U Rackmount Keyboard with USB, DEN | |
| AG079A | 1U Rackmount Keyboard with USB, NOR | |
| AG080A | 1U Rackmount Keyboard with USB, SE/FI | |
| AG081A | 1U Rackmount Keyboard with USB, SWI | |
| AG082A | 1U Rackmount Keyboard with USB, PORT | |
| AG083A | 1U Rackmount Keyboard with USB, BEL | |
| AG084A | 1U Rackmount Keyboard with USB, JPN2 | |
| AG085A | 1U Rackmount Keyboard with USB, RUS | |
| AG086A | 1U Rackmount Keyboard with USB, INTL | |
| AJ752A | HP 2012sa Single Controller Modular Smart Array | |
| AJ753A | HP 2012sa Dual Controller Modular Smart Array | |
| AJ766A | HP StorageWorks RDX160 External Removable Disk Backup System | |
| DC141B | USB 1.44-MB External Diskette Drive | |
| EJ001A | HP StorageWorks D2D2502i Backup System | |
| EJ002A | HP StorageWorks D2D2504i Backup System | |
| U4479E | Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years, Electronic | |
| U4480E | 4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic | |
| U4481E | 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic | |
| U4482E | 6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic | |
| U4490E | Hardware Installation, Electronic | |
| U4491E | Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic | |
| U4492E | Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic | |
| U4493E | Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic | |
| U6309E | Onsite HW support 24x7, 4hr response and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic. | |
| U8331E | Onsite HW support 24x7, 4hr response and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic. | |
