配件信息 |
|
FC号 |
PN号 |
描述 |
|
CPU |
|
|
597868-B21 |
HP DL980 G7 Intel® Xeon® E7520 (1.86GHz/4-core/18MB/95W) 4-processor Kit |
|
|
597869-B21 |
HP DL980 G7 Intel® Xeon® E6540 (2GHz/6-core/18MB/105W) 4-processor Kit |
|
|
597870-B21 |
HP DL980 G7 Intel® Xeon® X6550 (2GHz/8-core/18MB/130W) 4-processor Kit |
|
|
597871-B21 |
HP DL980 G7 Intel® Xeon® X7560 (2.27GHz/8-core/24MB/130W) 4-processor Kit |
|
|
650766-B21 |
HP DL980 G7 Intel® Xeon® E7-4807 (1.86GHz/6-core/18MB/95W) 4-processor Kit |
|
|
650766-L21 |
HP DL980 G7 Intel® Xeon® E7-4807 (1.86GHz/6-core/18MB/95W) FIO 4-processor Kit |
|
|
650767-B21 |
HP DL980 G7 Intel® Xeon® E7-2830 (2.13GHz/8-core/24MB/105W) 4-processor Kit |
|
|
650767-L21 |
HP DL980 G7 Intel® Xeon® E7-2830 (2.13GHz/8-core/24MB/105W) FIO 4-processor Kit |
|
|
650768-B21 |
HP DL980 G7 Intel® Xeon® E7-2850 (2.0Ghz/10-core/24MB/130W) 4-processor Kit |
|
|
650768-L21 |
HP DL980 G7 Intel® Xeon® E7-2850 (2.0Ghz/10-core/24MB/130W) FIO 4-processor Kit |
|
|
650769-B21 |
HP DL980 G7 Intel® Xeon® E7-2860 (2.26GHz/10-core/24MB/130W) 4-processor Kit |
|
|
650769-L21 |
HP DL980 G7 Intel® Xeon® E7-2860 (2.26GHz/10-core/24MB/130W) FIO 4-processor Kit |
|
|
650770-B21 |
HP DL980 G7 Intel® Xeon® E7-4870 (2.4GHz/10-core/30MB/130W) 4-processor Kit |
|
|
650770-L21 |
HP DL980 G7 Intel® Xeon® E7-4870 (2.4GHz/10-core/30MB/130W) FIO 4-processor Kit |
|
内存 |
|
|
500656-B21 |
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit |
|
|
519808-B21 |
HP 512MB DDR2 244P Mini DIMM Module Kit |
|
|
534562-B21 |
HP 1GB Flash Backed Cache |
|
|
534916-B21 |
HP 512MB Flash Backed Write Cache |
|
|
593339-B21 |
HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit |
|
硬盘 |
|
|
507127-B21 |
HP 300GB 6G SAS 10K SFF (2.5-inch) Dual Port Enterprise 3 years Warranty Hard Drive |
|
|
512545-B21 |
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise Hard Drive |
|
|
512547-B21 |
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise Hard Drive |
|
|
572071-B21 |
HP 60GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive |
|
|
572073-B21 |
HP 120GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive |
|
|
581284-B21 |
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive |
|
|
581286-B21 |
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive |
|
|
619291-B21 |
HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive |
|
|
632492-B21 |
HP 200GB 6G SAS SLC SFF (2.5-inch) Enterprise Performance 3yr Warranty Solid State Drive |
|
|
632494-B21 |
HP 400GB 6G SAS SLC SFF (2.5-inch) Enterprise Performance 3yr Warranty Solid State Drive |
|
SCSI卡 |
|
AH627A |
|
HP U320e SCSI Dual Channel Host Bus Adapter |
|
网卡 |
|
|
458492-B21 |
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter |
|
|
489892-B21 |
HP NC524SFP Dual Port 10GbE Module |
|
|
503746-B21 |
HP NC112T PCI Express Gigabit Server Adapter |
|
|
538696-B21 |
HP NC375T PCI Express Quad Port Gigabit Server Adapter |
|
|
581201-B21 |
HP NC550SFP Dual Port 10GbE Server Adapter |
|
|
593717-B21 |
HP NC523SFP 10Gb 2-port Server Adapter |
|
|
593722-B21/593743-001 |
HP NC365T 4-port Ethernet Server Adapter |
|
|
614203-B21 |
HP NC552SFP 10Gb 2-port Ethernet Server Adapter |
|
适配卡 |
|
|
262587-B21 |
PS/2 adapter - Allows connection to CAT5 Server Console Switch KVM or IP Console Switch KVM using Category 5 (CAT5) cable - Package contains one adapter |
|
|
262588-B21 |
KVM Cat5 USB interface adapter - Includes one adapter |
|
|
412648-B21 |
HP NC360T PCI Express Dual Port Gigabit Server Adapter |
|
|
572531-B21 |
HP Smart Array P411/1G FBWC 2-ports Ext PCIe x8 SAS Controller |
|
|
578229-B21 |
HP Smart Array P411/512 FBWC 2-ports Ext PCIe x8 SAS Controller |
|
|
592520-B21 |
HP InfiniBand 4X QDR ConnectX-2 PCIe G2 Dual Port HCA |
|
|
592521-B21 |
HP InfiniBand 4X DDR ConnectX-2 PCIe G2 Dual Port HCA |
|
|
614988-B21 |
HP Modular Smart Array SC08e 2-ports Ext PCIe x8 SAS Host Bus Adapter |
|
|
AF604A |
HP 1-pack PS/2 Virtual Media Interface Adapter |
|
|
AW520A |
HP StorageWorks CN1000E Dual Port Converged Network Adapter |
|
光纤卡 |
|
|
A8002A |
HP StorageWorks FC2142SR PCI Express 4Gb Host Bus Adapter |
|
|
A8003A |
HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e Host Bus Adapter |
|
|
AE311A |
HP StorageWorks FC1142 4Gb PCI-Express Host Bus Adapter |
|
|
AE312A |
HP StorageWorks FC1242SR 4Gb PCIe dual-channel Host Bus Adapter |
|
|
AJ763A |
HP StorageWorks 82E 8Gb Dual-port PCI Express Fiber Channel Host Bus Adapter |
|
|
AJ764A |
HP StorageWorks 82Q 8Gb Dual Port PCIe Fiber Channel Host Bus Adapter |
|
|
AK344A |
HP StorageWorks 81Q PCIe Fiber Channel Host Bus Adapter |
|
|
AP767A |
HP StorageWorks 41B PCI Express 4Gb Host Bus Adapter - Single port, fiber channel |
|
|
AP768A |
HP StorageWorks 42B PCI Express 4Gb Host Bus Adapter - Dual port, fiber channel |
|
|
AP769A |
HP StorageWorks PCI Express 8Gb Host Bus Adapter - Single port, fiber channel |
|
|
AP770A |
HP StorageWorks PCI Express 8Gb Host Bus Adapter - Dual port, fiber channel |
|
电源 |
|
|
252663-B31 |
HP Modular Power Distribution Units (mPDU), High Volt Model, 32A (200-240 VAC) (Int’l) |
|
|
AF416A |
HP R5500 VA UPS, INTL |
|
|
AF453A |
HP R/T3000 UPS, High voltage, NA/JPN |
|
|
AF454A |
HP R/T3000 UPS, High voltage, detachable inlet cord INTL |
|
|
AF460A |
HP R5KVA 3U L630 High Voltage Uninterruptible Power System |
|
|
AF461A |
HP R5KVA 3U IEC309-32A High Voltage INTL Uninterruptible Power System |
|
|
AF462A |
HP R7KVA 4U 50A High Voltage Uninterruptible Power System |
|
|
AF463A |
HP R7KVA 4U IEC-32A High Voltage INTL Uninterruptible Power System |
|
|
AF466A |
HP R/T3000 G2 2U L530 Low Voltage Uninterruptible Power System |
|
|
AF467A |
HP R/T3000 G2 2U L620 High Voltage Uninterruptible Power System |
|
|
AF468A |
HP R/T3000 G2 2U Detachable Cord High Voltage INTL Uninterruptible Power System |
|
|
AF469A |
HP R1.5kVA G3 1U Uninterruptible Power System |
|
|
AF470A |
HP R1.5kVA G3 1U JP/TW Uninterruptible Power System |
|
|
AF471A |
HP R1.5kVA G3 1U INTL Uninterruptible Power System |
|
|
AF508A |
HP 11 kVA S1316 Monitored PDU- single input, 3U, 16A (INTL) |
|
|
AF510A |
HP 7.3kVA S1132 Monitored PDU- single input, 1U, 32A (INTL) |
|
|
AF914A |
HP 4.9kVA 24A Single Input Single Phase Monitored Power Distribution Unit |
|
|
AF915A |
HP 7.3 kVA S132 Monitored PDU- single input, 1Ø, 32A (INTL) |
|
|
AM470A |
HP DL980 1200W Common Slot Platinum Hot Plug Power Supply Kit |
|
电池 |
|
|
462969-B21 |
HP 650 mAh P-Series Battery |
|
光驱 |
|
|
481041-B21 |
HP Slim SATA DVD-ROM Optical Drive |
|
|
481043-B21 |
HP Slim SATA DVDRW Optical Drive |
|
磁带机 |
|
|
AJ830A |
HP DAT 320 SAS Internal Tape Drive |
|
|
AP835A |
HP StorageWorks DAT 320 USB Tape Drive in 1U USB Rack Kit |
|
|
BL536A |
HP 1/8 G2 LTO-5 Ultrium 3000 SAS Tape Autoloader |
|
|
BL537A |
HP MSL2024 1 LTO-5 Ultrium 3000 SAS Tape Library |
|
|
BL538A |
HP MSL4048 2 LTO-5 Ultrium 3000 SAS Tape Library |
|
|
BL539A |
HP StorageWorks MSL8096 2 LTO-5 Ultrium 3000 SAS Tape Library |
|
|
EH847A |
HP StorageWorks Ultrium 920 SAS Internal Tape Drive |
|
|
EH860A |
HP StorageWorks LTO-4 Ultrium 1840 SAS Internal Tape Drive |
|
|
EH899A |
HP StorageWorks LTO-5 Ultrium 3280 Internal Tape Drive |
|
|
EH919A |
HP StorageWorks LTO-4 Ultrium 1760 SAS Internal Tape Drive |
|
导轨 |
|
|
AF092A |
HP 10642 G2 1200mm deep Shock Rack |
|
|
AF094A |
HP 10647 G2 1200mm deep Shock Rack |
|
线缆 |
|
|
631660-B21 |
HP DL580/DL585/DL980 G7 Power Cable Kit |
|
|
AF612A |
HP 1x4 KVM Console 6ft USB Cable - Server console cable for USB Keyboard, Video, Mouse (KVM) - 1.82m (6ft) long - Two cables are included |
|
其它 |
|
|
252663-B24 |
HP Modular Power Distribution Unit(mPDU), High Volt Model, 16A (200-240 VAC) (WW) |
|
|
364430-B21 |
HP StorageWorks 50 Modular Smart Array |
|
|
433257-B21 |
HP Cluster Management Utility Media |
|
|
436222-B21 |
HP Insight Software Media Kit |
|
|
452148-B22 |
HP Insight Control suite, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates |
|
|
452151-B21 |
HP Insight Rapid Deployment software No Media 1-Server License including 1 year of 24x7 Technical Support and Updates |
|
|
462830-B21 |
HP Smart Array P411/256 2-ports Ext PCIe x8 SAS Controller |
|
|
462834-B21 |
HP Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 SAS Controller |
|
|
487204-B21 |
HP Smart Array P812/1G FBWC 2-ports Int/4-ports Ext PCIe x8 SAS Controller |
|
|
488069-B21 |
HP Trusted Platform Module Option |
|
|
512485-B21 |
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Single Server License |
|
|
516471-B21 |
HP Smart Array Advanced Pack including 1yr 24x7 Technical Support and Updates Single Server License |
|
|
580387-B21 |
HP 4GB Secure Digital High Capacity Flash Media Kit |
|
|
582765-B21 |
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Single Server FIO License |
|
|
588137-B21 |
HP DL580 G7 PCI Express Kit |
|
|
588139-B21 |
HP DL580 G7 PCI-X Combo Express Kit |
|
|
588141-B21 |
HP DL580G7/DL980G7 Memory Cartridge |
|
|
600278-B21 |
HP 160GB Single Level Cell PCIe ioDrive for ProLiant Servers |
|
|
600279-B21 |
HP 320GB Multi Level Cell PCIe ioDrive for ProLiant Servers |
|
|
600281-B21 |
HP 320GB Single Level Cell PCIe ioDrive Duo for ProLiant Servers |
|
|
600282-B21 |
HP 640GB Multi Level Cell PCIe ioDrive Duo for ProLiant Servers |
|
|
608447-B21 |
HP 2GB USB Flash Media Drive Key Kit |
|
|
641027-B21 |
HP 1.28TB Multi Level Cell PCIe IO Accelerator |
|
|
A0R60A |
HP DL980G7 (E7) Memory Cartridge |
|
|
AF001A |
10642 G2 (42U) Rack Cabinet - Pallet |
|
|
AF002A |
10642 G2 (42U) Rack Cabinet - Shock Pallet |
|
|
AF031A |
10647 G2 (47U) Rack Cabinet - Pallet |
|
|
AF426A |
HP Rack Uninterruptible Power System R5500 (North America or Japan) |
|
|
AF504A |
HP monitored single Power Distribution Unit (PDU) S1324 (North America, Japan) - 3PH, 24A, 8.6 kVA |
|
|
AF506A |
HP Single Input 1 Phase 40A Monitored Power Distribution Unit (North America, Japan) |
|
|
AF611A |
HP 1x4 USB/PS2 KVM console switch |
|
|
AF616A |
HP Server Console 0x2x8 Port Analog Switch |
|
|
AF617A |
HP Server Console 0x2x16 Port Analog Switch |
|
|
AF618A |
HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software |
|
|
AF619A |
HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software |
|
|
AF621A |
HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software |
|
|
AF622A |
HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software |
|
|
AJ934A |
HP RDX500 Internal Removable Disk Backup System |
|
|
AM434A |
Low Profile PCI Express I/O Expansion Kit |
|
|
AM450A |
HP DL980 E7 Series CPU Installation Assembly |
|
|
AM451A |
HP ProLiant DL980 G7 Configure-to-order Server |
|
|
DC172B |
HP USB 2-Button Optical scrolling mouse (Carbonite Black and Silver) - Has 1.8m (6.0 feet) long cable with USB connector |
|
|
DT528A#ABA |
HP Keyboard (USB) standard 2004 |
|
|
EH993B |
HP D2D4112 Backup System |
|
|
EJ002B |
HP D2D2504i Backup System |
|
|
QL803A |
HP Cluster Management Utility Flexible License |
|
|
T9074BAE |
HP Insight Control including 1yr 24x7 Technical Support and Updates Electronic License |
|
|
T9082AAE |
HP Insight Control Server Deployment including 1yr 24x7 Support Electronic License |
|
|
TA850AAE |
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Electronic License |
|
|
TC203A |
HP Insight Control for Linux including 1yr 24x7 Support ML/DL Bundle 1 Server FIO License |
|
|
TC208A |
HP Insight Control for Linux Media Kit |
|
|
TC209A |
HP Insight Control for Linux including 1yr 24x7 Support Single Server License |
|
|
TC213AAE |
HP Insight Control for Linux including 1yr 24x7 Support Electronic License |
|
|
TC275A |
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Tracking License |
|
|
TC278AAE |
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Electronic License |
|
|
TC293B |
HP High Performance Computing Linux Value Pack 1 Processor Flexible License |
|
|
TC294A |
HP High Performance Computing Linux Value Pack Media Kit |
|
|
U4618E |
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic |
|
|
U5683E |
Installation and Startup for Essentials Rapid Deployment Pack, Electronic |
|
|
UV292E |
HP 3 year 6 hour 24x7 Call To Repair ProLiant DL980 Hardware Support |
|
|
UV298E |
HP 3 year 4 hour 24x7 ProLiant DL980 Hardware Support |
|
|
UV301E |
HP 3 year 4 hour 13x5 ProLiant DL980 Hardware Support |
|
|
|
HP Install ProLiant DL980 Hardware only |
|
|
UX131E |
HP 3 year Support Plus 24 for Microsoft OS ProLiant DL980 Service |
|
|
UX132E |
HP 3 year Support Plus 24 for Linux Red Hat ProLiant DL980 Service |
|
|
UX133E |
HP 3 year Support Plus 24 for Linux SuSe ProLiant DL980 Service |
