HP/惠普 ProLiant DL160 G5服务器,入门级的1U高机架式服务器, 占用空间小,可配置2颗CPU,内存32Gb,可满足较常规的应用以及可用于小型内部局域网环境使用,价格相对低廉,欲了解更多DL160 G5服务器的更多资讯,请联系广州鑫瑞信息
整机信息 | |
名称 | HP ProLiant DL160 G5 Server series |
型号 | |
品牌 | HP |
类型 | PC服务器 |
CPU信息 | 标配一个,最大两个CPU。 |
CPU类型 | 英特尔®至强 Xeon X5472处理器 |
CPU插槽数 | 2 |
CPU激活 | 不需要激活 |
机架类型 | 机架式 |
机架空间 | 1U |
硬盘信息 | 最大内部存储非热插拔SATA 2TB 4x500GB;热插拔SATA 3TB 4x750GB;非热插拔SAS 1.2TB 4x300GB;热插拔SAS 1.2TB 4x300GB。 |
最大硬盘数量 | 4 |
内存提示 | 类型PC2-5300全缓冲内存插槽(DDR2-667) |
支持内存容量范围 | 最大32GB (8x4GB) |
内存插槽数量 | 8 |
内存是否需要激活 | 不需要激活 |
电源描述 | 650瓦,自动切换,PFC (功率因数校正) |
单机电源数量 | 1 |
介质托架 | 可选的DVD光驱 |
适配器插槽 | 非热插拔型1个全长全高PCI-E x16 (2代),1个半高 PCI-Ex16 (2代);热插拔型1全长全高PCI-Ex16 (2 代),1个半高PCI-X,均可转换. |
端口 | RJ-45网络接口(以太网) 2 个10/100/1000网卡端口(外加 1个HP ProLiant Lights Out 100i远程管理的专用端口);串行端口1;定位设备(鼠标) 1;显卡1;键盘1;USB端口5 个(正面 2个,内置1 个,背面2 个)。 |
发布日期 | |
下架日期 | |
服务截止期 | |
操作系统 | Microsoft Windows 2003 和Microsoft Windows 2003/R2 Standard Edition (32-bit); Microsoft Windows 2003 和Microsoft Windows 2003/R2 Enterprise Edition (32-bit); Microsoft Windows 2003 和Microsoft Windows 2003/R2 Web Edition (32-bit); Microsoft Windows 2003 和Microsoft Windows 2003/R2 for Extended Systems Standard Edition (64-bit); Microsoft Windows 2003 和Microsoft Windows 2003/R2 for Extended Systems Enterprise Edition (64-bit); Red Hat Enterprise Linux; SUSE Linux Enterprise Server; Solaris 10. |
产品尺寸 | (高x宽x长) (带支架) 4.32x44.80x68.20厘米(1.70x17.64x26.85英寸) |
产品重量 | 最大(所有已安装的硬盘驱动器、电源和处理器) 16.78千克(37.00磅);最小(已安装的1 个硬盘驱动器、电源和处理器) 13.69 千克(30.00磅)。 |
HP ProLiant DL160 G5服务器的配件参数详情>>>>>>
配件信息 | ||
FC号 | PN号 | 描述 |
CPU | ||
446077-B21 | Intel Xeon E5405 2.0GHz Quad Core 12MB DL160 G5 Processor Option Kit | |
448365-B21 | Intel Xeon E5472 3.0GHz Quad Core 12MB DL160 G5 Processor Option Kit | |
448369-B21 | Intel Xeon L5410 2.33GHz Quad Core 12MB DL160 G5 Processor Option Kit | |
448371-B21 | Intel Xeon X5272 3.40GHz Dual Core 6MB DL160 G5 Processor Option Kit | |
452664-001 | Intel Xeon processor - 2.0GHz (Clovertown, 1333MHz, 8MB cache, Quad-Core, 50W, FSB, Low Voltage) - Includes thermal grease and alcohol pad | |
457876-001 | Intel Xeon Quad Core processor E5405 - 2.0GHz (Harpertown, 1333MHz, 2x6MB Level-2 cache, socket LGA 775, 80W TDP) - Includes thermal grease and alcohol pad | |
457877-001 | Intel Xeon Quad Core processor E5430 - 2.66GHz (Harpertown, 1333MHz front side bus, LGA771 socket, 80W TDP) - Includes thermal grease and alcohol pad | |
457880-001 | Intel Xeon Quad Core processor X5472 - 3.0GHz (Harpertown, 1600MHz front side bus, 120-Watt) | |
459734-001 | Intel Xeon E5462 Quad-Core processor - 2.80GHz (Harpertown, 12M Level-2 cache, 1600MHz front side bus, 80W TDP, socket LGA 771) | |
459736-001 | Intel Xeon Quad Core processor L5410 - 2.33GHz (Harpertown, 1333MHz, 2x6MB level-2 cache, Quad-Core, 50W, FSB) - Includes thermal grease and alcohol pad | |
459737-001 | Intel Xeon processor - 3.4GHz (Wolfdale, 1600MHz, dual-core, 80W) - Includes thermal grease and alcohol pad | |
460492-001 | Intel Xeon E5410 Quad Core processor - 2.33GHz (Clovertown, 1333MHz front side bus, 12MB total Level-2 cache, LGA771 socket) - Includes thermal grease and alcohol pad | |
462778-001 | Intel Xeon Quad Core processor E5405 - 2.0GHz (Harpertown, 1333MHz front side bus, 12MB Level-2 cache, socket 775, 45nm process) | |
462781-001 | Intel Xeon Quad Core processor E5430 - 2.66GHz (Harpertown, 1333MHz front side bus, 12MB Level-2 cache, socket 775, 45nm process) | |
463719-001 | Intel Xeon Quad Core processor L5420 - 2.50GHz (Harpertown, 1333MHz front side bus, LGA771 socket, 50W TDP) - Includes thermal grease and alcohol pad | |
系统板 | ||
445986-B21 | HP PCI-X Riser Board Kit | |
452341-001 | Hard disk drive backplane board - 2-port, 1U, 4.5cm (1.75in) | |
452698-B21 | HP DL16XG5 PCI-X Riser Kit | |
457882-001 | System board | |
460016-001 | PCI-e x16 riser board - Low Power (LP), half height | |
500387-001 | System board | |
内存 | ||
397409-B21 | 1 GB FBD PC2-5300 2 x 512 MB Single Rank Kit | |
397411-B21 | 2 GB FBD PC2-5300 2 x 1 GB Dual Rank Kit | |
397413-B21 | 4 GB FBD PC2-5300 2 x 2 GB Dual Rank Kit | |
397415-B21 | 8 GB FBD PC2-5300 2 x 4 GB Dual Rank Kit | |
398706-051/416471-001 | 1.0GB, 667MHz, PC2-5300, registered DDR2 Fully Buffered DIMMs (FBD) memory module | |
405148-B21 | 512 MB Battery-backed write cache upgrade | |
405836-001 | 256MB battery backed write cache (BBWC) memory board - 40-bit, DDR - For Smart Array P400 controller | |
413015-B21 | 16 GB FBD PC2-5300 2 x 8 GB Dual Rank Kit | |
416470-001 | 512MB, 667MHz, PC2-5300, fully buffered, registered DDR2 FBDIMM memory module | |
416472-001 | 2.0GB (128Mx4), 667MHz, PC2-5300, registered DDR2 Fully Buffered DIMMs (FBD) memory module | |
416473-001 | 4.0GB, 667MHz, PC2-5300, Fully Buffered DIMMs (FBD), registered DDR2 memory module | |
446557-001 | 1GB, 667MHz, PC2-5300, Fully Buffered DIMMs (FBD) memory module | |
448049-001 | 2GB (1 DIMM) memory module, 667MHz, PC2-5300, fully buffered DIMMs (FBD) | |
448050-001 | 512MB (1 DIMM) memory module, 667MHz, PC2-5300, fully buffered DIMMs (FBD) | |
455442-001 | 2.0GB PC2-5300 Low Power (LP) DDR2 SDRAM Fully Buffered DIMM (FBD) memory module | |
461826-B21 | 2 GB FBD PC2-5300 2 x 1 GB Low Power Single Rank Kit | |
461828-B21 | 4 GB FBD PC2-5300 2 x 2 GB Low Power Dual Rank Kit | |
466440-B21 | 8 GB FBD PC2-5300 2 x 4 GB Low Power Dual Rank Kit | |
467654-001 | 4.0GB, PC2-5300F, low power, 4x256M DIMM memory module | |
484062-B21 | HP 8GB FBD PC2-6400 2x4GB Dual Rank Memory Kit | |
486450-001 | 4GB, PC2-6400 Fully Buffered (FB), CAS Latency (CL5) DIMM memory module | |
491834-001 | 4GB, PC2-5300F, QRx8 DIMM memory module | |
493006-001 | 4.0GB memory module, PC2-5300F DDR2-667MHz, Fully Buffered DIMMs (FBD), ECC Registered | |
495604-B21 | 64 GB FBD PC2-5300 8 x 8 GB Dual Rank Kit | |
硬盘 | ||
135427-001 | 28.5GB hard drive - 7,200 RPM | |
373312-001 | 160GB non-hot-plug Serial ATA (SATA) hard drive - 7,200 RPM | |
376594-001 | 72GB hot-plug Serial Attached SCSI (SAS) hard drive - 15,000 RPM, 3.5-inch form factor (Part of 375870-B21) | |
397552-001 | 160GB hot-plug Serial ATA (SATA) hard drive - 7,200 RPM, 3.5-inch form factor, 1.0-inch high (Part of 349238-B21) | |
397553-001 | 250GB hot-plug Serial ATA (SATA) hard drive - 7,200 RPM, 1.5GB-sec transfer rate, 3.5-inch form factor | |
399466-001 | 250GB hot-plug Serial ATA (SATA) hard drive - 7,200RPM, front loading | |
399968-001 | 160GB non-hot-plug Serial ATA (SATA)-150 hard drive - 7,200 RPM, 3.5-inch form factor (LFF) | |
432150-001 | 146GB non-hot-plug Serial Attached SCSI (SAS) hard drive - 15,000 RPM, 3.5-inch form factor | |
459317-001 | 160GB hot-plug Serial ATA (SATA) hard drive - 7,200 RPM, 1.5G, 3.5-inch form factor (LFF), NCQ (Native Command Queing) | |
459320-001 | 750GB hot-swap Serial ATA (SATA) hard drive - 7,200 RPM, 3Gbps transfer rate with Native Command Queuing (NCQ), 3.5-inch small form factor (SFF) | |
493883-001 | 500GB Serial ATA (SATA) hard drive disk - 7,200 RPM, 3.5-inch form factor | |
RAID卡 | ||
012891-001/412799-001 | Smart Array E200/64 - PCIe Serial Attached SCSI (SAS) RAID controller card (Part of 409180-B21) | |
347786-B21 | HP 8 Internal Port SAS 64/133 PCI-X RAID Host Bus Adapter | |
SCSI卡 | ||
012970-001/412800-001 | Smart Array E200i controller cache module - 64MB, 40-bit - Without battery | |
405832-001 | Serial Attached SCSI (SAS) Smart Array P400 controller - Has right-angle connectors on the front-side of the board for use on rx3600 and rx6600 servers | |
445202-001 | HP DL160 G5 E5405 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (United States) | |
445202-421 | HP DL160 G5 E5405 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (Europe) | |
445202-AA1 | HP DL160 G5 E5405 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (China) | |
445203-001 | HP DL160 G5 E5430 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (United States) | |
445203-421 | HP DL160 G5 E5430 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (Europe) | |
445203-AA1 | HP DL160 G5 E5430 1GB Hot-Swapable (HP) Serial Attached SCSI (SAS)/Serial ATA (SATA) Server (China) | |
447431-001 | Serial Attached SCSI (SAS) Host Bus Adapter (HBA) - Has four internal ports with RAID - Half height (HH) | |
453833-001 | SA E200 128MB battery-backed write cache (BBWC) module - For RAID 5, 40-bit | |
454514-001 | Serial Attached SCSI (SAS)/Serial ATA (SATA) backplane (secondary) - 4-bay media cage models only | |
AH627A | HP U320e SCSI Dual Channel Host Bus Adapter | |
网卡 | ||
394795-B21 | HP NC380T PCI-Express dual-port multifunction gigabit server adapter | |
434905-B21 | HP NC110T single-port copper single-lane (x1) PCI-Express 10/100/1000 Base-T gigabit server adapter board | |
458492-B21 | HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter | |
468332-B21 | HP NC522SFP Dual Port 10GbE Gigabit Server Adapter | |
适配卡 | ||
373983-B21 | Myrinet 2XP PCI-X 4MB F-series Fiber Card | |
394791-B21 | HP NC373T PCI Express Multifunction Gigabit Server Adapter | |
394793-B21 | HP NC373F PCI Express Multifunction Gigabit Server Adapter | |
412648-B21 | HP NC360T PCI Express Dual Port Gigabit Server Adapter | |
416096-B21 | HP SC44Ge Host Bus Adapter | |
447430-001 | SC40GE Host Bus Adapter (HBA) - Serial ATA (SATA) / Serial Attached SCSI (SAS) PCI Express - Half height | |
448397-B21 | HP IB 4X DDR PCI-e Dual Port HCA | |
448398-B21 | HP InfiniBand 4X DDR PCI-E Single Port Host Channel Adapter (HCA) | |
457871-001 | PCI-e x16 riser board - Low Power (LP), full height | |
462790-001 | PCI-e NVIDIA Quadro FX 3700 512MB graphics card - With G-DDR3 graphics memory, up to 32x Full-Scene Anti Aliasing (FSAA) | |
490062-B21 | NVIDIA Quadro FX3700 512MB PCI-E Adpater | |
490646-B21 | HP NVIDIA Quadro FX1700 512MB PCI-E Adapter | |
光纤卡 | ||
A8002A | HP StorageWorks FC2142SR PCI Express 4Gb Host Bus Adapter | |
A8003A | HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e Host Bus Adapter | |
AD167A | HP StorageWorks FC2143 4Gb PCI-X 2.0 Host Bus Adapter (HBA) | |
AD168A | HP StorageWorks FC2243 Dual Channel 4GB PCI-X 2.0 Host Bus Adapter (HBA) | |
AE311A | HP StorageWorks FC1142 4Gb PCI-Express Host Bus Adapter | |
AE312A | HP StorageWorks FC1242SR 4Gb PCIe dual-channel Host Bus Adapter | |
电源 | ||
441830-001 | Power supply (1200W) - Hot plug, 1U, 12V DC output | |
453650-B21 | HP 1200W High Efficiency Power Supply Kit, Factory Integration Only (FIO) | |
457626-001 | Power supply kit - 650W, 1U | |
电池 | ||
383280-B21 | HP Smart Array Cache Battery Kit - For Smart Array P400 Controller only | |
398648-001 | 4.8V, 500mAh, Ni-MH battery - For use with 512MB battery backed write cache (BBWC) module | |
光驱 | ||
158729-001 | ATAPI IDE DVD-ROM drive - 8X speed - 5.25-inch, half-height form factor | |
403709-001 | DVD-ROM drive (Multibay II) - 8X read speed (Part of PA849A) | |
436952-001 | CD/DVD combo drive - 24X, 9-mm (4-drive models only) - Includes bracket | |
447889-B21 | HP 1U 9.5mm DVD-ROM Drive Option Kit | |
447891-B21 | HP DVD/CD RW Combo Drive Kit - IU 9.5MM 24X | |
462485-001 | IDE DVD/CD-RW combo drive - 24X/24X/24X/8X speed, 9.5mm high | |
磁带机 | ||
AD606B | HP StorageWorks MSL6030 1 Ultrium 960 Dr LVDS Library | |
AD607B | HP StorageWorks MSL6030 2 Ultrium 960 Dr LVDS Library | |
AD608B | HP StorageWorks MSL6030 1 Ultrium 960 Dr FC Library | |
AD609B | HP StorageWorks MSL6030 2 Ultrium 960 Dr FC Library | |
AE313B | HP StorageWorks DAT 72x10 tape autoloader | |
AG115A | HP StorageWorks MSL2024 1 LTO-3 Ultrium 960 SCSI Drive Library | |
AG116A | HP StorageWorks Midrange Storage Library MSL2024 1 Ultrium 448 SCSI Tape Drive Library | |
AG320A | HP Midrange Storage Library (MSL) 4048 1 Ultrium 448 Tape Drive Library | |
AG322A | HP StorageWorks Midrange Storage Library (MSL) 4048 1 Ultrium 960 SCSI Tape Drive Library | |
AG324B | HP StorageWorks MSL4048 1 Ultrium 960 4GB FC Drive Library | |
AG326B | HP StorageWorks MSL2024 1 Ultrium 960 4GB FC Drive Library | |
AG594A | HP StorageWorks 1U USB Rack-Mount Kit with one DAT 72 USB Tape Drive | |
AH163A | HP StorageWorks 1/8 Ultrium 232 G2 Tape Autoloader | |
AH164A | HP 1/8 Ultrium 448 G2 Tape Autoloader | |
AH165A | HP StorageWorks 1/8 G2 LTO-3 Ultrium 920 Tape Autoloader | |
AH166A | HP 1/8 G2 Tape Autoloader Rack Kit | |
AH169A | HP StorageWorks MSL2024 1 Ultrium 920 Drive Library | |
AH171A | HP StorageWorks MSL4048 1 Ultrium 920 Drive Library | |
AH218A | HP StorageWorks MSL8096 2 LTO-3 Ultrium 960 4GB FC Library | |
AH219A | HP StorageWorks MSL8096 2 LTO-3 Ultrium 960 SCSI Drive Library | |
AH558A | HP StorageWorks 1/8 G2 Ultrium 920 SAS Tape Autoloader | |
AH559A | HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library | |
AH560A | HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library | |
AH561A | HP StorageWorks MSL8096 2 LTO-3 Ultrium 920 SAS Drive Library | |
AJ029A | HP StorageWorks MSL6030 1 LTO-4 Ultrium 1840 SCSI Drive Library | |
AJ030A | HP StorageWorks MSL6030 1 LTO-4 Ultrium 1840 4GB FC Library | |
AJ031A | HP StorageWorks MSL6060 2 LTO-4 Ultrium 1840 SCSI Drive Library | |
AJ032A | HP StorageWorks MSL6060 2 LTO-4 Ultrium 1840 4GB FC Library | |
AJ033A | HP StorageWorks MSL2024 1 LTO-4 Ultrium 1840 Tape Library | |
AJ034A | HP StorageWorks MSL2024 1 LTO-4 Ultrium 1840 4GB FC Library | |
AJ035A | HP StorageWorks MSL4048 1 LTO-4 Ultrium 1840 SCSI Drive Library | |
AJ036A | HP StorageWorks MSL4048 1 LTO-4 Ultrium 1840 4GB FC Library | |
AJ039A | HP StorageWorks MSL8096 2 LTO-4 Ultrium 1840 SCSI Drive Library | |
AJ040A | HP StorageWorks MSL8096 2 LTO-4 Ultrium 1840 4GB FC Library | |
DW028B | HP StorageWorks 1U SCSI Rack-mount kit with one LTO-2 Ultrium 448 SCSI Tape Drive (Carbonite) | |
DW064A | HP StorageWorks Ultrium 232 Internal Tape Drive (Carbonite) | |
DW085A | HP StorageWorks Ultrium 448 SAS Internal Tape Drive | |
EH847A | HP StorageWorks Ultrium 920 SAS Internal Tape Drive | |
EH880A | HP StorageWorks DAT 160 USB Internal Tape Drive | |
EH903A | HP StorageWorks 1U SCSI Rack-mount kit with one LTO-3 Ultrium 920 | |
EH926A | HP StorageWorks 3U SCSI Rack-Mount with 1 LTO-4 Ultrium 1840 Tape Drive | |
Q1595B | HP StorageWorks 3U SCSI Rack-mount kit with one Ultrium 960 (Carbonite) | |
风扇 | ||
457873-001 | Fan assembly - 1U (4.5 cm) height, one unit per kit | |
457881-001 | Processor heatsink | |
导轨 | ||
274338-B22 | HP StorageWorks 3U Rack-Mount Kit | |
461513-001 | Rack-mounting hardware kit - Rails | |
A7445B | HP StorageWorks 1U SCSI Rack Mount Kit - Supports up to two half-height tape drives | |
A8007A | HP StorageWorks Rack-Mount Kits - 1U for factor, USB | |
AE459A | HP StorageWorks 1U SAS Rack Mount Kit - Supports up to two half-height tape drives and is compatible with the Ultrium 448 SAS and Ultrium 920 SAS tape drives | |
线缆 | ||
142258-002 | Power cord (Black) - For power Distribution Unit (PDU) - IEC 320 C14 (M) connector to IEC 320 C13 (F) connector - 2.5m (8.2ft) long - 250V, 16A | |
146447-003 | SCSI cable - Elongated for Smart Array Controller SA5300 when installed in slots ten or eleven | |
409125-001 | Battery cable assembly - 28AWG, 16-pin - 60.9cm (24in) long | |
452333-001 | Serial ATA (SATA) cable - 250mm (9.8in) long | |
452334-001 | Serial ATA (SATA) data cable - 1U rackmounts, 0.4500m (1.4764 feet) long - Optical Disk Drive (ODD) | |
452337-001 | Jumper hard disk drive backplane cable - M/S | |
454356-001 | Integrated Drive Electronics (IDE) Optical Disk Drive (ODD) cable - 1U/2U | |
504238-001 | Power cable for memory | |
504239-001 | Power cable for power supply - 650W | |
504240-001 | Graphic card power cable | |
其它 | ||
116378-001 | Miscellaneous Hardware Kit | |
122214-001 | Top access panel | |
146765-001 | KIT,SPS-BUN,SHIPPING(Q=1 SET) | |
405132-B21 | HP Smart Array P400/256MB Controller | |
410531-001 | 4x1x16 IP server console switch | |
411508-B21 | HP Smart Array E200/128 BBWC Controller | |
413965-001 | Torx tool - Includes T-15/T-10 L-head | |
435129-B21 | HP Smart Array E500/256MB Controller | |
445196-001 | HP DL160 G5 E5405 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (United States) | |
445196-371 | HP DL160 G5 E5405 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (Asia Pacific) | |
445196-421 | HP DL160 G5 E5405 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (United States) | |
445196-AA1 | HP DL160 G5 E5405 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (China) | |
445197-001 | HP DL160 G5 E5430 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (United States) | |
445197-421 | HP DL160 G5 E5430 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (United States) | |
445197-AA1 | HP DL160 G5 E5430 1GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (China) | |
445198-001 | HP DL160 G5 E5472 2GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (United States) | |
445198-421 | HP DL160 G5 X5472 2GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (Europe) | |
445198-AA1 | HP DL160 G5 X5472 2GB Non-Hot-Swapable (NHP) Serial ATA (SATA) Server (China) | |
445985-B21 | HP Hard Drive Backplane 1U 2S Kit | |
452345-001 | Plastic and hardware spares kit - Includes right and left fan clips, removable blank hard disk drive, L-wrench, and screws | |
453652-B21 | HP Backplane 1U 2S Kit | |
454347-001 | Primary access panel - Top cover | |
454348-001 | Plastics kit - Includes screws, removable and fixed hard disk drive blanks, air baffle, optical blank, torx L-wrench, torx key, non-hot-plug power supply cover, power supply blank, PCI guides/latch | |
454367-001 | Mounting hardware kit - 1U/2U - Includes right and left slide rails, LC2U rail kit, and installation instructions | |
458749-001 | PCI module cage - 1U (4.5 cm) height | |
459162-001 | DC to DC converter and backplane assembly board - 750W, 1U, 4.5cm (1.75in) | |
459187-001 | Bezel - Removable hard drive bezel blank | |
459732-001 | Miscellaneous plastics and hardware kit - Includes air baffle, right and left bezels (4 bay), bezel (2 bay), air blocker, and foam cable guide | |
460019-001 | Hard disk drive cage - Large Form Factor (LFF), 1U | |
460020-001 | Optical Disc Drive (ODD) bezel blank - 1U | |
460023-001 | Air baffle | |
462421-001 | Non-hot-plug four-hard disk drive cage - For DL16X servers | |
462422-001 | Hot-plug four-hard disk drive cage - For DL16X servers | |
462484-001 | 9.5mm (0.3in) Printed Circuit Asembly (PCA) bracket - For DL160 G5 | |
469239-001 | Top cover for hard drive cage | |
500388-001 | Air baffle | |
530834-001 | HP StorageWorks M6412FC disk enclosure | |
EH884A | HP StorageWorks D2D120 Backup System | |
EH923A | HP StorageWorks D2D110 Backup System with Data Protector Express Software Kit | |
EH924A | HP StorageWorks D2D120 Backup System with Data Protector Express Software Kit |
