FC号 |
PN号 |
描述 |
|
CPU |
|
|
44E4478 |
2.13 GHz 65W (six core) (MT 7233,7234) |
|
|
44E4479 |
2.13 GHz 90W 8M (quad core) (MT 7233, 7234) |
|
|
44E4480 |
2.13 GHz 90W 12M (quad core) (MT 7233, 7234) |
|
|
44E4481 |
2.4 GHz 90W (quad core) (MT 7233, 7234) |
|
|
44E4482 |
2.4 GHz 90W (six core) (MT 7233, 7234) |
|
|
44E4483 |
2.67 GHz 130W (six core) (MT 7233, 7234) |
|
|
44E4516 |
2.13 GHz 50W (quad core) (MT 7233,7234) |
|
3644 |
44E4465 |
Six Core Intel Xeon Processor X7460 (2.66GHz 16MB L3 130w) |
|
3645 |
44E4455 |
Six Core Intel Xeon Processor L7455 (2.13GHz 12MB L3 65w) |
|
3646 |
44E4461 |
Quad Core Intel Xeon Processor E7440 (2.40GHz 16MB L3 90w) |
|
3647 |
44E4457 |
Quad Core Intel Xeon Processor E7420 (2.13GHz 8MB L3 90w) |
|
3648 |
44E4459 |
Quad Core Intel Xeon Processor E7430 (2.13GHz 12MB L3 90w) |
|
3649 |
44E4463 |
Six Core Intel Xeon Processor E7450 (2.40GHz 12MB L3 90w) |
|
4416 |
44E4466/44E4473 |
Addl. Intel Xeon Processor x7460 (6 Cores 2.66GHz 16MB L3 Cache) |
|
4417 |
44E4456/44E4468 |
Addl. Intel Xeon Processor L7455 (6 Cores 2.13GHz 12MB L3 Cache) |
|
4418 |
44E4462/44E4471 |
Addl. Intel Xeon Processor E7440 (4 Cores 2.4GHz 16MB L3 Cache) |
|
4419 |
44E4458/44E4469 |
Addl. Intel Xeon Processor E7420 (4 Cores 2.13GHz 8MB L3 Cache) |
|
4420 |
44E4460/44E4470 |
Addl. Intel Xeon Processor E7430 (4 Cores 2.13GHz 12MB L3 Cache) |
|
4421 |
44E4464/44E4472 |
Addl. Intel Xeon Processor E7450 (6 Cores 2.4GHz 12MB L3 Cache) |
|
4435 |
44E4515/44E4517 |
Addl. Intel Xeon Processor L7445 (4 Cores 2.13GHz 12MB L3 Cache) |
|
6976 |
44E4514 |
Quad Core Intel Xeon Processor L7445 (2.13GHz 12MB L3 50W) |
|
系统板 |
|
|
43W8672 |
Memory card |
|
|
43W8673 |
Power backplane. |
|
|
44E4488 |
Microprocessor-board assembly (MT 7233, 7234). |
|
|
44W2728 |
SAS hard disk drive backplane |
|
4894 |
43W8606/44E4252 |
MemoryONupFVY0p.. Expansion Card |
|
内存 |
|
|
41Y2762 |
2GB (2x 1GB) DDR 2 667MHz DIMM memory Kit |
|
|
41Y2768 |
8GB (2x4GB) PC2-5300 CL3 ECC DDR2 SDRAM RDIMM |
|
|
41Y2771 |
4GB (2x2GB) PC2-5300 CL5 ECC DDR2 667MHz SR RDIMM |
|
|
43V7356 |
16GB Kit (2x 8GB DIMM) PC2-5300 CL5 ECC DDR2 SDRAM LP RDIMM4 |
|
3935 |
41Y2760/41Y2761 |
1GB PC2-5300 CL5 ECC DDR2 SDRAM RDIMM |
|
3937 |
41Y2766/41Y2851 |
4GB PC2-5300 CL5 ECC DDR2 SDRAM RDIMM |
|
3938 |
43V7354/43V7355 |
8GB PC2-5300 CL5 ECC DDR2 SDRAM RDIMM |
|
3939 |
41Y2769/41Y2770 |
2GB PC2-5300 CL5 ECC DDR2 SDRAM RDIMM |
|
硬盘 |
|
|
40K1052/39R7366 |
73GB 10K 2.5" Hot-Swap SAS HDD |
|
97 |
46M0889/46M0878 |
IBM 320GB High IOPS SD Class SSD PCIe Adapter. |
|
3746 |
43W7723/43W7722 |
IBM 50GB SATA 2.5" SFF HS High IOPS SSD SFF |
|
5199 |
42D0654/42D0652 |
IBM 146GB 15K 6Gbps SAS |
|
5410 |
42D0694/42D0692 |
IBM 500GB 7200 6Gbps NL SAS 2.5" SFF HS |
|
5509 |
42D0612/42D0613/42D0614 |
IBM 300GB 10K 6Gbps SAS |
|
5534 |
43X0824/43X0825/43X0826 |
146GB 10K 2.5" Hot-Swap SAS HDD |
|
5543 |
43X0841/43X0837/43X0839 |
73GB SAS 15K 2.5" SFF HS |
|
RAID卡 |
|
3557 |
43W4281/43W4280/43W4282 |
ServeRAID-MR10k SAS/SATA |
|
3559 |
43W4340/44E8825/43W4339 |
ServeRAID-MR10is VAULT SAS/SATA Controller |
|
SCSI卡 |
|
|
43W4324 |
IBM Ultra 320 SCSI PCIe Controller |
|
网卡 |
|
1485 |
39ONupFVY0p..Y6071/39Y6066 |
NetXtreme II 1000 Express G Ethernet Adapter- PCIe |
|
1637 |
42C1823/42C1820/42C1822 |
Brocade 10Gb CNA for IBM System x PCIe 8x |
|
2944 |
39Y6129/39Y6126 |
PRO/1000 PT Dual Port Server Adapter by Intel |
|
2974 |
39Y6138/39Y6139/39Y6136 |
PRO/1000 PT Quad Port Server Adapter |
|
2978 |
42C1762/42C1763/42C1760 |
IBM 10 GbE PCIe SR Server Adapter |
|
2995 |
42C1783/42C1780/49Y4205 |
NetXtreme II 1000 Express Dual Port Ethernet |
|
5451 |
42C1792/42C1793/42C1790 |
NetXtreme II 10 GigE Express Fiber SR Adapter |
|
5751 |
42C18ONupFVY0p..00/42C1802/42C1803 |
QLogic 10Gb CNA for IBM System x PCI-E |
|
5766 |
49Y4223/49Y4220 |
NetXtreme II 1000 Express Quad Port Ethernet Adapter |
|
5767 |
49Y4233/49Y4230 |
Intel Ethernet Dual Port Server Adapter I340- T2 for IBM System x |
|
5768 |
49Y4243/49Y4240 |
Intel Ethernet Quad Port Server Adapter I340- T4 for IBM System x |
|
适配卡 |
|
|
25R8060 |
IBM SAS HBA Controller2 |
|
|
44E4373 |
PCI switch-card assembly |
|
96 |
46M0888/46M0877 |
IBM 160GB High IOPS SS Class SSD PCIe adapter. |
|
1649 |
46M0900/46M0898 |
IBM 320GB High IOPS MS Class SSD PCIe Adapter. |
|
2975 |
42C1752/42C1753/42C1750 |
PRO/1000 PF Server Adapter Half x4 PCIe by intel. |
|
2976 |
39Y6148/39Y6149/39Y6146 |
QLogic iSCSI Single Port PCIe HBA for IBM System x |
|
2977 |
42C1772/42C1773/42C1770 |
QLogic iSCSI Dual Port PCIe HBA for IBM System x |
|
3583 |
44E8702/44E8700 |
IBM 3Gb SAS HBA Controller v2 - PCI-E x8 1,2 N 2 |
|
光纤卡 |
|
1698 |
43W7491/42C2069/42C2070 |
Emulex 4Gb FC Single-Port PCI-E HBA for IBM System x |
|
1699 |
43W7492/42C2071/42C2072 |
Emulex 4Gb FC Dual-Port PCI-E HBA for IBM System x |
|
3567 |
42C2179/39R6525/39R6526 |
QLogic 4Gb FC Single-Port PCIe HBA for IBM System x |
|
3568 |
42C2182/39R6527/39R6528 |
QLogic 4Gb FC Dual-Port PCIe HBA for IBM System x |
|
3578 |
42D0502/42D0501/42D0507 |
QLogic 8Gb FC Single-port HBA for IBM System x |
|
3579 |
42D0511/42D0510/42D0516 |
QLogic 8Gb FC Dual-port HBA for IBM System x |
|
3580 |
42D0486/42D0485/42D0491 |
Emulex 8Gb FC Single-port HBA for IBM System x |
|
3581 |
42D0495/42D0494/42D0500 |
Emulex 8Gb FC Dual-port HBA for IBM System x |
|
3589 |
46M6051/46M6049/42D0549/42D6049/46M6061 |
Brocade 8Gb FC Single-port HBA for IBM System x |
|
3591 |
46M6052/46M6050/46M6062 |
Brocade 8Gb FC Dual-port HBA for IBM System x |
|
3885 |
59Y1988/59Y1987/59Y1992 |
Brocade 4Gb FC Single-port HBA for IBM System x |
|
3886 |
59Y1994/59Y1993/59Y1998 |
Brocade 4Gb FC Dual-port HBA for IBM System x |
|
电源 |
|
|
21301RX |
IBM UPS3000 LV |
|
|
21302RX |
IBM UPS3000 HV |
|
|
21303RX |
IBM UPS 7500Xhv |
|
|
21304RX |
IBM UPS 10000Xhv |
|
|
24195KX |
IBM UPS5000 HV |
|
|
39Y8857 |
IBM UPS 3U Online Battery Pack |
|
1991 |
43WONupFVY0p..8614/59Y6142 |
1440W Power Supply |
|
电池 |
|
|
33F8354 |
3.0 V battery |
|
|
43W4283 |
Battery for ServeRAID-MR10k SAS/SATA Controller. |
|
|
43W4342 |
Battery. |
|
光驱 |
|
|
43W4609 |
DVD-RW drive (MT 7141) |
|
|
44W3255 |
DVD/CD-RW Drive, SATA (MT 7233, 7234) |
|
|
44W3256 |
DVD SATA multi-burner (MT 7233, 7234) |
|
4161 |
44W3251/46M0901 |
IBM UltraSlim Enhanced SATA DVD-ROM |
|
4162 |
44W3252 |
UltraSlim Enhanced SATA CD-RW / DVD-ROM Combo |
|
4163 |
44W3253/46M0902 |
IBM UltraSlim Enhanced SATA Multi-Burner |
|
磁带机 |
|
|
87651UX |
1U Tape Drive Enclosure |
|
|
8767HHX |
Half High Tape Drive Enclosure |
|
5364 |
39M5621/39M5658 |
IBM Half High LTO Gen 2 Tape Drive 2 SCSI 89mm |
|
5392 |
43W8487/43W8480 |
IBM DDS Gen 5 SATA Tape Drive10 3.5" systems |
|
5393 |
43W8490/43W8478 |
IBM Half High LTO Gen 3 SAS Tape Drive |
|
5395 |
43W8492/39M5636 |
IBM DDS Gen 6 USB Tape Drive |
|
5397 |
44E8897/44E8895 |
IBM Half-high LTO Gen 4 SAS Tape Drive |
|
风扇 |
|
|
43W9559 |
Heat sink |
|
|
43W9578 |
Fan (92 mm) |
|
|
44E4563 |
Fan (120 mm) |
|
导轨 |
|
|
44E4570 |
EIA mounting bracket (right and left) (all models) |
|
线缆 |
|
|
31R3132 |
IBONupFVY0p..M 3M Console Switch Cable (USB) |
|
其它 |
|
|
172317X |
1U 17in Flat Panel Console Kit |
|
|
172319X |
1U 19in Flat Panel Console Kit |
|
|
172621X |
IBM System Storage DS3200 |
|
|
172622X |
IBM System Storage DS3200 |
|
|
172631X |
IBM System Storage DS3300 iSCSI Single Controller Model |
|
|
172632X |
IBM System Storage DS3300 iSCSI Dual Controller Model |
|
|
172641X |
IBM System Storage DS3400 |
|
|
172642X |
IBM System Storage DS3400 |
|
|
172701X |
IBM System Storage EXP3000 |
|
|
17351GX |
IBM Local 2x8 Console Manager (LCM2) |
|
|
17352GX |
IBM Global 2x16 Console Mngr(GCM2) |
|
|
17353LX |
IBM 1 x 8 Console Switch |
|
|
17354LX |
IBM 2 x 16 Console Switch |
|
|
1754D1X |
IBM Global 2X2X16 Console Manager |
|
|
1754D2X |
IBM Global 4X2X32 Console Manager |
|
|
362516X |
IBM RDX 160 GB External USB Drive |
|
|
362532X |
IBM RDX 320 GB External USB Drive |
|
|
362550X |
IBM RDX 500 GB External USB Drive |
|
|
39M2816 |
IBM Dpi C13 PDU+ |
|
|
39Y8923 |
IBM Enterprise C19 3 phase PDU (60a) |
|
|
39Y8941 |
IBM Enterprise C13 PDU |
|
|
39Y8948 |
IBM Enterprise C19 PDU |
|
|
40K1692 |
IBM External USB Floppy Drive |
|
|
40K5372 |
IBM Keyboard w/ Integrated Pointing Device USB - US English 103P |
|
|
41Y8268 |
IBM USB Memory Key for VMware Hypervisor |
|
|
42C1816 |
Qlogic 10 GB SFP+ SR optical transceiver |
|
|
42D0545 |
2 GB Hypervisor flash device |
|
|
44E4249 |
IBM XpandOnDemand Scalability Kit (2-3 Node)1 |
|
|
44E4250 |
4-Chassis Cable Kit1 |
|
|
44E4372 |
Operator information panel assembly |
|
|
44E4529 |
DVD housing with interposer card assembly (MT 7233, 7234) |
|
|
44E4553 |
Microprocessor VRM |
|
|
44E4576 |
Fan cage |
|
|
44E4587 |
Miscellaneous hardware parts: M6 screws for slide rails (4x), RSA II knob, left and right shipping brackets. |
|
|
46C5364 |
IBM RDX160 Internal USB Bundle |
|
|
46C5387 |
IBM RDX320 Internal USB Bundle |
|
|
46C5388 |
IBM RDX500 Internal USB Bundle |
|
|
46M3510 |
Chassis assembly |
|
|
46M3511 |
Media-hood assembly |
|
|
46M4002 |
IBM 1U 9 C19/3 C13 Switched and Monitored DPI PDU |
|
|
46M4003 |
IBM 1U 9 C19/3 C13 Switched and Monitored 60A 3 Phase PDU |
|
|
46M4004 |
IBM 1U 12 C13 Switched and Monitored DPI PDU |
|
|
46M4005 |
IBM 1U 12 C13 Switched and Monitored 60A 3 Phase PDU |
|
|
46M5968 |
Remote Supervisor Adapter II |
|
|
71762MX |
IBM Ultra Density Enterprise C19/C13 PDU+ Module |
|
|
71762NX |
IBM Ultra Density Enterprise C19/C13 PDU Module |
|
|
71763MU |
IBM Ultra Density Enterprise C19/C13 PDU+ 60A/208V/3ph |
|
|
71763NU |
IBM Ultra Density Enterprise C19/C13 PDU 60A/208V/3ph |
|
|
93072PX |
IBM S2 25U Static Base Cabinet |
|
|
93072RX |
IBM 25U S2 standard rack |
|
|
93074RX |
NetBAY S2 42U Standard Rack Cabinet |
|
|
93074XX |
IBM 42U S2 expansion rack |
|
|
93084EX |
IBM 42U Enterprise Expansion Rack |
|
|
93084PX |
IBM 42U Enterprise Rack |
|
|
99564RX |
IBM S2 42U Dynamic Standard Rack Cabinet |
|
|
99564XX |
IBM S2 42U Dynamic Expansion Rack Cabinet |
|
1749 |
59Y8348/41Y8283 |
IBM USB Memory Key for VMware ESXi 3.5 Update 5 |
|
1774 |
40K6887/41Y8269 |
IBM USB Memory Key for VMware ESXi 3.5 Update 4 |
|
1776 |
46M4989/41Y8278 |
IBM USB Memory Key for VMware ESXi 47 |
|
2018 |
|
IBM 11U Office Enablement Kit |
|
3756 |
39Y7960/39M2895 |
IBM USB Conversion Option Pack |
|
3757 |
39Y8072/43V6147 |
IBM Single Cable USB Conversion Option (UCO) |
|
3758 |
39Y7957/39M2894 |
Virtual Media Conversion Option |
|
5340 |
69Y2045/46M5382 |
IBM Serial Conversion Option (SCO) |
|
5341 |
69Y2046/46M5383 |
IBM Virtual Media Conversion Option Gen2 (VCO2) |
|
8750 |
40K9490/40K9584 |
IBM Preferred Pro Keyboard USB - US English 103P |
|
8912 |
40K9491/40K9200 |
IBM 2 Button Optical Wheel Mouse - Black - USB |
|
8913 |
40K9492/40K9201 |
IBM 3 Button Optical Mouse - Black - USB |
