2U机架式服务器，最大可以扩展至16个硬盘，单颗CPU支持上9根内存，双CPU可支持18根，其扩展性很强大，内存最大可以支持144Gb，欲了解更多X3650 M3服务器的咨询，请联系广州鑫瑞信息
| 联想/IBM服务器 X3650 M3整机信息 | |
| 名称 | IBM System x3650 M3 HF |
| 型号 | 5454 |
| 品牌 | IBM |
| 类型 | PC服务器 |
| CPU信息 | Up to two six-core (up to 3.46GHz) or quad-core (up to 3.6GHz) Intel Xeon 5600 series processors with QuickPath Interconnect technology up to 6.4 GT/s, and up to 1333MHz memory speed. Also supports the Intel Xeon X5698 4.4GHz dual-core processor. Supports specific Quad-core and Dual-core Intel Xeon 5500 series processors via Configure-To-Order (CTO). |
| CPU类型 | Intel Xeon 5600 系列 |
| CPU插槽数 | 2 |
| CPU激活 | 不需要激活 |
| 机架类型 | 机架式 |
| 机架空间 | |
| 硬盘信息 | 最大14.4TB。 |
| 最大硬盘数量 | 16 |
| 内存提示 | |
| 支持内存容量范围 | 4-144Gb |
| 内存插槽数量 | 最大18跟内存插槽位，每个CPU9根。 |
| 内存是否需要激活 | 不需要激活 |
| 电源描述 | |
| 单机电源数量 | 2 |
| 介质托架 | One, support for DVD-ROM or Multiburner. Separate bay. Optional Tape Enablement Kit is available to support one DDS5, DDS6, or RDX internal tape drive. If used, the maximum number of HDD bays is limited to 8. |
| 适配器插槽 | Up to 5 (up to 4 available, one slot is dedicated to RAID controller), dependant on the riser cards used (three different riser cards are available: 2x PCI-E x8 Gen 2, 1x PCI-E x16 Gen 2, and 2x PCI-X 64 bit/133MHz). Up to two riser cards are supported. |
| 端口 | |
| 发布日期 | |
| 下架日期 | |
| 服务截止期 | |
| 操作系统 | Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux 5 and 6, SUSE Linux Enterprise Server 10 and 11, VMware ESX 4.1 and VMware ESXi 4.1 embedded hypervisor, Sun Solaris 10. |
| 产品尺寸 | |
| 产品重量 |
|
IBM X3650 M3 HF(5454)服务器配件详情>>>>>>>>
|
配件信息
|
||
| FC号 | PN号 | 描述 |
| CPU | ||
| A1EE | 90Y4650 | Addl Intel Xeon Processor X5698 2C 4.40GHz 12M Cache 1333MHz 130W |
| A1EF | 90Y4649 | Intel Xeon Processor X5698 2C 4.40GHz 12M Cache 1333MHz 130W |
| 内存 | ||
| 8923 | 49Y1379/49Y1397 | 8GB (1x8GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM |
| 8941 | 49Y1388/49Y1406 | 4GB (1x4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM |
| 8942 | 49Y1389/49Y1407 | 4GB (1x4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3 1333MHz LP RDIMM |
| 硬盘 | ||
| 5433 | 49Y2005/49Y2003 | IBM 600GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD SFF |
| 5536 | 42D0679/42D0677 | IBM 146GB 15K 6Gbps SAS 2.5" SFF Slim-HS HDD SFF |
| RAID卡 | ||
| 93 | 46M0850/46M0829 | ServeRAID M5015 SAS/SATA Controller (Battery not included) |
| 94 | 46M0853/46M0830 | ServeRAID M5025 SAS/SATA Controller - PCI-E x8 |
| 网卡 | ||
| 1637 | 42C1823/42C1820/42C1822 | Brocade 10Gb CNA for IBM System x PCIe 8x |
| 3585 | 44X0137/46M1076 | Dual port 1Gb Ethernet Daughter Card n/a n/a Dedicated |
| 5451 | 42C1792/42C1793/42C1790 | NetXtreme II 10 GigE Express Fiber SR Adapter |
| 5751 | 42C1800/42C1802/42C1803 | QLogic 10Gb CNA for IBM System x PCI-E |
| 适配卡 | ||
| 69 | 49Y4217/49Y4216/42C1819 | Brocade 10Gb SFP+ SR Optical Transceiver |
| 3734 | 46M1131 | PCI-Express (2 x8 slots; 1 FH/FL, 1 FH/HL) |
| 5086 | 44X0138/46M1072 | PCI-Express (2 x8 slots; 1 FH/FL, 1 LP ) Riser |
| 光纤卡 | ||
| 3579 | 42D0511/42D0510/42D0516 | QLogic 8Gb FC Dual-port HBA for IBM System x |
| 3581 | 42D0495/42D0494/42D0500 | Emulex 8Gb FC Dual-port HBA for IBM System x |
| 3591 | 46M6052/46M6050/46M6062 | Brocade 8Gb FC Dual-port HBA for IBM System x |
| 电源 | ||
| 2100 | 44X0147/46M1075 | IBM 675W Redundant AC Power Supply |
| 电池 | ||
| 5744 | 46M0857/46M0917 | ServeRAID M5000 Series Battery Assembly |
| 光驱 | ||
| 4163 | 44W3253/46M0902 | IBM UltraSlim Enhanced SATA Multi-Burner |
| 线缆 | ||
| 3701 | 40K9805 | 5m LC-LC Fiber Cable (networking) |
| 3702 | 40K9806 | 25m LC-LC Fiber Cable (networking) |
| 3791 | 40K8932 | 0.6m Yellow Cat5e Cable |
| 3792 | 40K8935 | 1.5m Yellow Cat5e Cable |
| 3793 | 40K8960 | 3m Yellow Cat5e Cable |
| 3794 | 40K8939 | 10m Yellow Cat5e Cable |
| 3795 | 40K8941 | 25m Yellow Cat5e Cable |
| 3796 | 40K8963 | 0.6m Green Cat5e Cable |
| 3797 | 40K5627 | 1.5m Green Cat5e Cable |
| 3798 | 40K5791 | 3m Green Cat5e Cable |
| 3799 | 40K5792 | 10m Green Cat5e Cable |
| 3800 | 40K8868 | 25m Green Cat5e Cable |
| 3801 | 40K8949 | 0.6m Blue Cat5e Cable |
| 3802 | 40K5564 | 1.5m Blue Cat5e Cable |
| 3803 | 40K8936 | 3m Blue Cat5e Cable |
| 3804 | 40K8926 | 10m Blue Cat5e Cable |
| 3805 | 40K8929 | 25m Blue Cat5e Cable |
| 6316 | 39Y5532 | Rack power cable - 2.0m, 125-250V, C13 to IEC 320-C14 (WW) |
| 其它 | ||
| 5080 | 43V6923/46C7526 | IBM Virtual Media Key |
| 5106 | 46M0932/46M0930 | ServeRAID M5000 Series Advance Feature Key |
| A10C | 81Y4428/81Y4426 | ServeRAID M5000 Series Performance Accelerator Key |
