| 整机信息 | |
| 名称 | IBM P740 (8205-E6B) |
| 型号 | 8205-E6B |
| 品牌 | IBM |
| 类型 | 小型机 |
| CPU信息 |
4 核 或 8 核 3.3 GHz 或可选择 6 核 或 12 核 3.7 GHz 或 8 核 或 16 核 3.55 GHz POWER7 处理器。 |
| CPU类型 | POWER7 |
| CPU插槽数 | 2 |
| CPU激活 | 需要激活码 |
| 机架类型 | 机架式，塔式 |
| 机架空间 | 4U |
| 硬盘信息 | 最大硬盘背板数量为 1 |
|
最大硬盘 数量 |
8 |
| 内存提示 | DDR3 的内存。 |
|
支持内存 容量范围 |
8GB-256GB |
|
内存插槽 数量 |
8-32（三个 FC#5604 Memory riser card） |
|
内存是否 需要激活 |
内存的容量不需要激活。 一台Power740最大支持 4个Memory riser card, 每个Memory riser card 支持8个内存槽位。其中 系统默认带一个Memory riser card，可需单独选配 3个Memory riser card， 其编号为：fc#5604。Active Memory Expansion 是 从POWER7开始支持的 一项新的内存虚拟技术， 需要激活码。Option (4794)-Power Active Memory Expansion Enablement |
| 电源描述 | 200v 到 240v 交流。 |
|
单机电源 数量 |
2 |
| 介质托架 |
用于 DVD-RAM 的薄型 托架，用于磁带驱动器 或可移动磁盘的半高托架。 |
| 适配器插槽 |
4 个 PCI Express 8x和 可选的 4 个PCI Express 薄型插槽。 |
| 端口 |
4 个以太网 10/100/1000 Mbps 端口（或）2 个 10 千兆 以太网端口，3 个 USB 端口， 2 HMC 端口，2 个串口， 2 个 SPCN 端口。 |
| IO适配器 |
1 SAS DASD/SSD 和 DVD-RAM 控制器，可选 175 MB 高速保护缓存。 |
| IO扩展 |
最多 4 个 PCIe 12x I/O 抽屉， 最多 8 个 PCI-x DDR 12x I/O 抽屉。 |
| 发布日期 | 2010/1/17 |
| 下架日期 | |
| 服务截止期 | |
| 操作系统 | AIX, IBM I, LinuX f或者 POWER®。 |
| 产品尺寸 | 桌面型：21.3 |
| 产品重量 |
桌面型： 48.2 千克（106 磅）， 机架扩展笼：37.3 千克（82 磅）。 |
| 配件信息 | ||
| FC号 | PN号 | 描述 |
| CPU | ||
| 8347 | 539E/74Y6155 |
4-core 3.7GHz POWER7 Processor Module |
| 8353 | 535E/74Y6152 |
4-core 3.3GHz POWER7 Processor Module |
| 8354 | 539D/74Y6153 |
6-core 3.72GHz POWER7 Processor Module |
| 8355 | 539F/74Y6154 |
8-core 3.55GHz POWER7 Processor Module |
| 系统板 | ||
| 2BE6/74Y2288 |
PCIe expansion assembly (Gen2) |
|
| 46K7514 | Memory riser | |
| 52C3/74Y1706 | System VPD card | |
| 5610 |
2BDD/46K5417/ 74Y3019 |
PCIe Riser Card (Gen1) |
| 内存 | ||
| 4525 |
04N2568/04N2967/ 19P2481/73H2601/ 81F8902/93H8055/ 97H7330/97H7610/ 97H7796 |
4GB (2x2GB) Memory DIMMs, 1066MHz, 2GB DDR3 DRAM |
| 4526 | 77P8784 |
8GB (2x4GB) Memory DIMMs, 1066MHz, 2GB DDR3 DRAM |
| 4529 | 77P8919 |
16GB (2x8GB) Memory DIMMs, 1066 MHz, 2GB DDR3 DRAM |
| 硬盘 | ||
| 19A3/74Y4897 |
571 GB 10K small form factor SAS disk drive (IBM® i) |
|
| 19A4/74Y9271 |
857 GB 10K small form factor SAS disk drive (IBM i) |
|
|
58B3/74Y5293/ 74Y5294 |
177 GB small form factor solid-state SAS drive for 9117-MMC, 9117-MMD, 9179-MHC, or 9179-MHD. |
|
| 58B8/74Y9524 |
387 GB small form factor solid-state SAS drive |
|
| 58B9/74Y9526 |
387 GB small form factor solid-state SAS drive |
|
| 74Y4900 |
600 GB 10K small form factor SAS disk drive |
|
| 74Y9272 |
900 GB 10K small form factor SAS disk drive |
|
| 1790 |
600GB 10K RPM SAS SFF Disk Drive (AIX/Linux) |
|
| 1793 |
177GB SFF-2 SSD w/ eMLC (AIX/Linux) |
|
| 1882 |
42R5661/42R8390/ 42R8392/46V6830/ 46V6837 |
146.8GB 10K RPM SAS SFF Disk Drive |
| 1883 |
44V4426/44V4427/ 44V4428/44V6842 |
73.4 GB 15K RPM SAS SFF Disk Drive |
| 1884 |
198B/44V4429/ 44V4430 |
69.7 GB 15K RPM SAS SFF Disk Drive |
| 1885 |
42R6833/44V6831/ 44V6833/44V6838 |
300GB 10K RPM SFF SAS Disk Drive |
| 1886 |
44V6843/44V6845/ 44V6850 |
146GB 15K RPM SFF SAS Disk Drive |
| 1888 |
198C/44V6844/ 00E6166 |
139 GB 15K small form factor SAS disk drive, IBM® i |
| 1890/1909 |
58B0/44V6817/ 44V6821/44V8674 |
69GB SFF SAS Solid State Drive |
| 1911 | 198D/74Y4896 |
283GB 10K RPM SFF SAS Disk Drive (IBM i) |
| 1917 |
146GB 15k RPM SAS SFF-2 Disk Drive (AIX/Linux) |
|
| 1925 |
300GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux) |
|
| 1964 |
600GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux) |
|
| 1995 | 58B2/43W7749 |
177GB SSD Module with eMLC (AIX/Linux) |
| 3586 |
58B0/44V6819/ 44V8673 |
69GB 3.5" SAS Solid State Drive |
| 3647 |
10N7203/10N7204/ 10N7232/42R4234 |
146 GB 15K RPM SAS Disk Drive |
| 3648 |
10N7207/10N7208/ 10N7234/42R5648 |
300 GB 15K RPM SAS Disk Drive |
| 3649 |
44V4432/44V4433/ 44V4438/44V4440 |
450 GB 15K RPM SAS Disk Drive |
| 4367 |
Bundle: 5 x #2055 and 20 x #1995 (AIX/Linux) |
|
| 硬盘背板 | ||
| 5618 |
2BD5/46K7496/ 00E0968 |
Disk drive backplane (supports six disk drives, one SATA DVD drive, and one SAS or USB tape drive) |
| 5630 |
2BD6/00E1078/ 46K7552 |
Disk drive backplane (supports eight disk drives, one SATA DVD drive, and one SAS or USB tape drive) |
| RAID卡 | ||
| 2053 |
43K6366/43K6367/ 74Y6409 |
PCIe LP RAID & SSD SAS Adapter 3Gb |
| 2054 |
43K6366/43K6367/ 74Y6409 |
PCIe RAID & SSD SAS Adapter 3Gb |
| 2055 |
43K6366/43K6367/ 74Y6409 |
PCIe RAID & SSD SAS Adapter 3Gb w/ Blind Swap Cassette |
| 5805 |
PCIe 380MB Cache Dual - x4 3Gb SAS RAID Adapter |
|
| 5908 |
42R3965/42T3969/ 44V4577/44V4579/ 44V5193/44V8622/ 46K4734/46K6114/ 74Y5665 |
PCI-X DDR 1.5GB Cache SAS RAID Adapter (BSC) |
| 5912 |
572A/44V4413/ 4V4414/44V5195/ 44V8579 |
PCI-X DDR Dual - x4 SAS Adapter |
| 5913 | 11P1346/11P3896 |
PCIe2 1.8GB Cache RAID SAS Adapter Tri-port 6Gb |
| 5923 | Non-paired PCIe SAS RAID Indicator | |
| 5924 |
Non-paired 6Gb/s PCIe SAS RAID Indicator |
|
| SCSI卡 | ||
| 5736 |
39J1643/39J2862/ 39J3536/39J4996/ 39J5022/42R4860/ 42R8736/44V5591/ 42R4362/52P8558 |
PCI-X DDR 2.0 Dual Channel Ultra320 SCSI Adapter |
| 5901 |
57B3/44V4852/ 44V8580/45K4732 |
PCIe Dual-x4 SAS Adapter |
| 网卡 | ||
| 5271 |
PCIe Low Profile 4-Port 10/100/1000 Base-TX Ethernet Adapter |
|
| 5272 | PCIe LP 10GbE CX4 1-port Adapter | |
| 5274 | PCIe LP 2-Port 1GbE SX Adapter | |
| 5275 | PCIe LP 10GbE SR 1-port Adapter | |
| 5284 | PCIe2 LP 2-port 10GbE SR Adapter | |
| 5286 |
PCIe2 LP 2-Port 10GbE SFP+ Copper Adapter |
|
| 5287 | 74Y2095 | PCIe2 2-port 10 GbE fiber card |
| 5288 | 74Y2094 |
(#5288) -PCIe2 2-Port 10GbE SFP+Copper Adapter |
| 5706 |
00G2380/00P4289/ 00P6131/03N5297/ 03N6070/53P5450/ 80P4024/80P7033 |
IBM 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter |
| 5717 |
10N7405/10N8556/ 46Y3512 |
4-Port 10/100/1000 Base-TX PCI Express Adapter |
| 5732 |
45D4771/46K6696/ 46K7899 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 5740 | 03N5444 |
4-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter |
| 5767 |
10N6845/10N7405/ 46K6601 |
2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter |
| 5768 |
05H6768/10N6846/ 11P3847/12R9314/ 15R7536/46K6602 |
2-Port Gigabit Ethernet-SX PCI Express Adapter |
| 5769 |
05N6768/10N9505/ 11P3847/12R9314/ 46K7897 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 5772 |
576E/05N6768/ 10N9034/11P3847/ 12R9314 |
10 Gigabit Ethernet-CX4 PCIe (x8)Adapter |
| 适配卡 | ||
|
2BCF/44V8361/ 74Y6020/74Y3343 |
Cache battery card | |
|
2BD9/44V8353/ 74Y2071 |
RAID and cache storage controller | |
| 2BE1/46K7723 | RAID enablement card | |
| 1826 | 266F/74Y2003 |
Dual-port 10 Gb HEA Daughter Card (Copper) |
| 2728 |
57D1/46K6692/ 46K7494 |
4 port USB PCIe Adapter |
| 4764 |
12R6540/12R6714/ 41U0441/41U0442/ 41V0161 |
PCI-X Cryptographic Coprocessor (FIPS 4) |
| 4807 |
45D5803/45D6680/ 45D7948 |
PCIe Crypto Coprocessor No BSC 4765-001 |
| 4808 |
45D5803/45D6680/ 45D7948 |
PCIe Crypto Coprocessor Gen3 BSC 4765-001 |
| 5277 |
PCIe LP 4-Port Async EIA-232 Adapter |
|
| 5278 |
PCIe LP 2-x4-port SAS Adapter 3Gb |
|
| 5283 |
PCIe2 LP 2-Port 4X IB QDR Adapter 40Gb |
|
| 5615 |
2BDA/00E0646/ 2C1E/00E1088 |
GX book assembly(CCIN:2BDA) with 00E1088(CCIN:2C1E) GX adapter |
| 5631 |
2BE0/44V8368/ 44V8369 |
RAID storage controller (split disk drive function) |
| 5785 |
57D2/42R5143/ 46K6734/46K6735/ 6298965 |
4 Port Async EIA-232 PCIe Adapter |
| 显卡 | ||
| 5269 | 74Y2025 |
PCIe LP POWER GXT145 Graphics Accelerator |
| 5748 | 10N7756 |
POWER GXT145 PCI Express Graphics Accelerator |
| 光纤卡 | ||
| 5270 |
PCIe LP 10Gb FCoE 2-port Adapter |
|
| 5276 |
PCIe LP 4Gb 2-Port Fibre Channel Adapter |
|
| 5708 |
2B3B/05N6768/ 11P3847/12R9314/ 46K8088 |
10Gb FCoE PCIe Dual Port Adapter |
| 5713 |
03N6056/26K6490/ 30R5219/32R1926/ 46K7342/49Y4236 |
1 Gigabit iSCSI TOE PCI-X on Copper Media Adapter |
| 5735 |
577D/05N6768/ 10N9824/11P3847/ 12R9314/46C7006 |
8 Gigabit PCI Express Dual Port Fibre Channel Adapter |
| 5759 |
03N5027/03N5029/ 03N6768/10N8620/ 10N3847/12R9314 |
4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter |
| 5774 |
05N6768/10N7255/ 11P3847/12R9314/ 15R7536 |
4 Gigabit PCI Express Dual Port Fibre Channel Adapter |
| 电源 | ||
| 5603 | 2BCB/74Y5985 | System AC Power Supply, 1725 W |
| 稳压模块 | ||
| 51CB/74Y5451 | Processor VRM | |
| 51CC/74Y5453 | 80A memory VRM (C6) | |
| 51CD/74Y5455 | 20A memory VRM (C5) | |
| 电池 | ||
| 44V4359/74Y9628 | Time-of-day battery | |
| 光驱 | ||
| 5762 | 44V4219/44V4220 | SATA Slimline DVD-RAM Drive |
| 磁带机 | ||
| 5619 |
80/160GB DAT160 SAS Tape Drive |
|
| 5638 | 46C2007 | 1.5TB/3.0TB LTO-5 SAS Tape Drive |
| 5661 | 46C1932/46C1933 | DAT320 160/320 GB Tape Drive |
| 5673 | 46C1933/46K7434 | DAT320 160 GB USB Tape Drive |
| 5746 |
24R1922/35L2086/ 45E1126/45E1127/ 45E1129/95P4436/ 95P4450/96P1203 |
Half High 800GB/1.6TB LTO4 SAS Tape Drive |
| 磁带 | ||
| 5689 | 23R5635 | DAT160 Data Cartridge |
| 5747 |
IBM LTO Ultrium 4 800 GB Data Cartridge |
|
| 风扇 | ||
| 44V8326 | Heat sink | |
| 6B1D/74Y5220 | 120 mm fan assembly | |
| 74Y5221 |
40 mm Fan assembly on PCIe riser |
|
| 导轨 | ||
|
00E5669/59Y4919/ 49Y5312 |
Slide rail assembly with 49Y5312 Attaching screw for slide rail assembly |
|
| 6586 | 10N7683/80P3263 | Modem Tray for 19-Inch Rack |
| 7131 | 74Y5140 |
IBM Rack-mount Drawer Bezel and Hardware |
| 7145 |
46K5096/46K5097/ 49Y5312 |
IBM/OEM Rack-mount Drawer Rail Kit |
| 7841 | Ruggedize Rack Kit | |
| 线缆 | ||
| 46K4645 | Control panel cable (stand-alone) | |
| 46K4646 | Control panel cable (rack) | |
| 46K5029 | External SAS cable assembly | |
| 1025 |
42R5087/43L6774/ 75G3801/87G6236 |
Modem Cable - US/Canada and General Use |
| 1111 | CAT5E Ethernet Cable, 3M BLUE | |
| 1112 | CAT5E Ethernet Cable, 10M BLUE | |
| 1115 | CAT5E Ethernet Cable, 3M GREEN | |
| 1116 | CAT5E Ethernet Cable, 10M GREEN | |
| 1118 | CAT5E Ethernet Cable, 3M YELLOW | |
| 1119 | CAT5E Ethernet Cable, 10M YELLOW | |
| 1141 | 1-meter Cable for EXP4500 Switch | |
| 1143 | 3-meter Cable for EXP4500 Switch | |
| 1148 | EX4500 10GB Optical Transceiver | |
| 1827 | 39J5836/97P4299 | 3m RIO to RIO-2 Cable |
| 1828 | 15R8139/45D2235 |
1.5 Meter 12X to 4X Channel Conversion Cable |
| 1829 | 41V0226/42V2129 | 0.6 Meter 12X Cable |
| 1830 |
41V0227/42R6153/ 42V3130 |
1.5 Meter 12X cable |
| 1834 |
39J5642/42R6157/ 42R6160 |
8.0 Meter 12X Cable |
| 1840 | 42V2132 | 3.0 Meter 12X Cable |
| 1841 | 15R8140/45D2236 |
3 Meter 12X to 4X Channel Conversion Cable |
| 1854 |
10 Meter 12X to 4X Enhanced Channel Conversion Cable |
|
| 1861 | 44V3421/45D4785 | 0.6 Meter 12X DDR Cable |
| 1862 | 44V3423/45D4786 | 1.5 Meter 12X DDR Cable |
| 1864 | 45D4788 | 8.0 Meter 12X DDR Cable |
| 1865 |
44V3426/45D2571/ 45D5271 |
3.0 Meter 12X DDR Cable |
| 2118 |
01K6497/07L9628/ 76H0518 |
Converter Cable VHDCI to P Mini-68 pin to 68 pin 0.3M |
| 2124 |
09L3299/36R2585/ 41Y0596 |
Ultra 320 SCSI Cable 1 Meter |
| 2125 |
09L3301/36R2576/ 41Y0597 |
Ultra 320 SCSI Cable 3 Meter |
| 2126 |
09L3303/36R2577/ 41Y0598 |
Ultra 320 SCSI Cable 5 Meter |
| 2127 |
09L0881/09L3305/ 36R2578/41Y0599 |
Ultra 320 SCSI Cable 10 Meter |
| 2128 |
09L3307/19P1904/ 36R2579/41Y0600 |
Ultra 320 SCSI Cable 20 Meter |
| 2138 | 41Y0601/42D9817 | 0.55 Meter Ultra 320 SCSI Cable |
| 2456 |
09P3044/11P1352/ 11P1373/12R9321 |
LC-SC 50 Micron Fiber Converter Cable |
| 2459 |
00P4023/11P1374/ 12R9322 |
LC-SC 62.5 Micron Fiber Converter Cable |
| 2861 |
07L8817/87H3404/ 87H3405/87H3406/ 87H3439/87H3568 |
ARTIC960Hx 4-Port EIA-232 Cable |
| 2863 |
53G0638/87H3407/ 87H3408/87H3409/ 87H3566 |
ARTIC960Hx 4-Port X.21 Cable |
| 2864 |
87H3398/87H3399 /87H3400/87H3442/ 87H3565 |
ARTIC960Hx 4-Port V.35 (DTE Cable |
| 2934 |
10N6535/12H1204/ 40H0744/40H2206 |
Asynchronous Terminal/Printer Cable EIA-232 |
| 2936 |
30F9453/42R5206/ 53F3205/53F3662/ 6223741/6323741 |
Asynchronous Cable EIA-232/V.24 |
| 2951 |
33F8985/93H2899/ 93H5263 |
Cable V.24 / EIA-232 |
| 2952 |
71F0163/93H2900/ 93H5264 |
Cable V.35 |
| 2953 |
73H2508/93H2901/ 93H5265 |
Cable V.36 / EIA-499 |
| 2954 |
40F9904/93H2902/ 93H5267 |
Cable X.21 |
| 3124 |
10N7158/88G4771/ 88G4853 |
Serial to Serial Port Cable for Drawer/Drawer |
| 3125 |
10N7159/88G4772/ 88G4854 |
Serial to Serial Port Cable for Rack/Rack |
| 3287 |
1 meter Quad Data Rate InfiniBand Copper Cable, QSFP/QSFP |
|
| 3288 |
3m (9.8-ft.) IB/E'Net 40G Copper Cable QSFP/QSFP |
|
| 3289 |
5m QDR IB/E'Net Copper Cable QSFP/QSFP |
|
| 3290 |
10 meter Quad Data Rate InfiniBand Optical Cable, QSFP/ QSFP |
|
| 3293 |
30 meter Quad Data Rate InfiniBand Optical Cable, QSFP/ QSFP |
|
| 3652 | 42R6762/44V4147 | SAS Cable (EE Drawer to Drawer 1M |
| 3653 | 42R6727/44V4148 | SAS Cable (EE) Drawer to Drawer 3M |
| 3654 | 42R6728/44V4149 | SAS Cable (EE) Drawer to Drawer 6M |
| 3656 | 95P4084 | SAS SFF Cable |
| 3661 | 42R6742/44V4154 |
SAS Cable (X Adapter to SAS Enclosure Dual Controller/ Dual Path 3M |
| 3662 | 42R6743/44V4155 |
SAS Cable (X) Adapter to SAS Enclosure, Dual Controller/ Dual Path 6M |
| 3663 | 42R6744/44V4156 |
SAS Cable (X) Adapter to SAS Enclosure, Dual Controller/ Dual Path 15M |
| 3679 | 42R6751/44V4041 | SAS Cable (AI)-1M |
| 3681 | 44V4151/44V8231 | 3M SAS CABLE, ADPTR TO ADPTR (AA) |
| 3682 | 44V4152/44V8230 | 6M SAS CABLE, ADPTR TO ADPTR (AA) |
| 3684 | 42R8118/44V4163 |
SAS Cable (AE Adapter to Enclosure single controller/ single path 3M |
| 3685 | 42R8120/44V4164 |
SAS Cable (AE) Adapter to Enclosure, single controller/ single path 6M |
| 3686 | 42R6792/44V4161 |
SAS Cable (YI) System to SAS Enclosure, Single Controller/Dual Path 1.5M |
| 3687 | 42R6793/44V4162 |
SAS Cable (YI) System to SAS Enclosure, Single Controller/Dual Path 3M |
| 3688 | 44V5132 | SAS Cable (AT 0.6 Meter) |
| 3691 | 42R6788/44V4157 |
SAS Cable (YO Adapter to SAS Enclosure Single Controller/Dual Path 1.5 M |
| 3692 | 42R6789/44V4158 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 3 M |
| 3693 | 42R6790/44V4159 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 6 M |
| 3694 | 42R6791/44V4160 |
SAS Cable (YO) Adapter to SAS Enclosure, Single Controller/Dual Path 15 M |
| 3925 |
00P2165/23R4632/ 40H6328/40H6329 |
Serial Port Converter Cable 9-Pin to 25-Pin |
| 3926 | 00P2166 |
Asynch Printer/Terminal Cable 9-pin to 25-pin 4M |
| 3927 | 10N7712 |
Serial Port Null Modem Cable 9-pin to 9-pin 3.7M |
| 3928 | 10N7713 |
Serial Port Null Modem Cable 9-pin to 9-pin 10M |
| 3930 | System Serial Port Converter Cable | |
| 4242 |
07L9633/08L0491/ 42R4755 |
6 Foot Extender Cable for Displays (15 pin D-shell to 15 pin D-shell |
| 4256 |
00P2969/10N7374/ 32N1311/44P1375 |
Extender Cable - USB Keyboards 2M |
| 6001 | 00G1277/42F6839 | Power Control Cable (SPCN-2 meter) |
| 6006 |
09P1251/22R5239/ 93H8045 |
Power Control Cable (SPCN-3 meter) |
| 6007 |
21F9358/22R5221/ 55F4533 |
Power Control Cable (SPCN 15 meter) |
| 6008 |
21F9469/22R5219/ 55F4532/74F0188 |
Power Control Cable (SPCN 6 meter) |
| 6029 | 21F9359/22R5222 | Power Control Cable (SPCN 30 meter) |
| 6458 |
Power Cable- Drawer to IBM PDU 14-foot 250V/10A |
|
| 6460 |
Power Cord (14-foot Drawer To OEM PDU (125V 15A Plug Type #4 |
|
| 6469 |
Power Cord (14-foot Drawer to OEM PDU (250V 15A United States Plug Type #5 |
|
| 6470 |
Power Cord (6-foot To Wall (125V 15A Plug Type #4 |
|
| 6471 |
Power Cord (9-foot To Wall/OEM PDU (125V 15A Plug Type #70 |
|
| 6472 |
Power Cord (9-foot To Wall/OEM PDU (250V 16A Plug Type #18 |
|
| 6473 |
Power Cord (9-foot To Wall/OEM PDU (250V 10A Plug Type 19 |
|
| 6474 |
Power Cord (9-foot) To Wall/OEM PDU (250V 13A) Plug Type #23 |
|
| 6475 |
Power Cord (9-foot) To Wall/OEM PDU (250V 16A) Plug Type #32 |
|
| 6476 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #24 |
|
| 6477 |
Power Cord (9-foot) To Wall/OEM PDU （250V 16A) Plug Type #22 |
|
| 6478 |
Power Cord (9-foot) To Wall/OEM PDU (250V 16A) Plug Type #25 |
|
| 6479 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #6 |
|
| 6487 |
Power Cord (6-foot To Wall (250V 15A United States Plug Type #5 |
|
| 6488 |
Power Cord (9-foot To Wall/OEM PDU (125V 15A or 250V 10A Plug Type #2 |
|
| 6493 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #62 |
|
| 6494 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #69 |
|
| 6495 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #73 |
|
| 6496 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #66 |
|
| 6497 |
Power Cord (6-foot) To Wall/OEM PDU (250V 10A) Plug Type #10 |
|
| 6498 |
Power Cord (6-foot) To Wall/OEM PDU (250V 15A) Plug Type #34 |
|
| 6651 |
Power Cord (9-foot To Wall/OEM PDU (125V 15A Plug Type #75 |
|
| 6659 |
Power Cord (9-foot To Wall/OEM PD U (250V 15A Plug Type #76 |
|
| 6660 |
Power Cord (14-foot Drawer To OEM PDU (125V 15A Plug Type #59 (DENAN marking |
|
| 6665 |
Power Cord 3 M (10 ft Drawer to IBM PDU 250V/10A |
|
| 6669 |
Power Cord (14-foot Drawer to OEM PDU (250V 15A Plug Type #57 (DENAN marking |
|
| 6670 |
Power Cord (6-foot To Wall (125V 15A Plug Type #59 (DENAN marking |
|
| 6671 |
Power Cord (9-foot) Drawer to IBM PDU 250V/10A |
|
| 6672 |
Power Cord (5-foot) Drawer to IBM PDU 250V/10A |
|
| 6680 |
Power Cord (9-foot) To Wall/OEM PDU (250V 10A) Plug Type #6 Insulated |
|
| 6687 |
Power Cord (6-foot) To Wall (250V 15A) Plug Type #57 (DENAN marking) |
|
| 6771 |
Two 1M Intra-rack Fibre Channel Cables |
|
| 6773 |
Two 3M Intra-rack Fibre Channel Cables |
|
| 7801 |
16R0449/41V0479/ 52P7524 |
Ethernet Cable 6M Hardware Management Console to System Unit |
| 7802 |
05N5292/41V0143/ 52P7525 |
Ethernet Cable 15M Hardware Management Console to System Unit |
| EN01 |
1m (3.3-ft), 10GbE'Net Cable SFP+ Act Twinax Copper |
|
| EN02 |
3m (9.8-ft) 10GbE'Net Cable SFP+ Act Twinax Copper |
|
| EN03 |
5m (16.4-ft) 10GbE'Net Cable SFP+ Act Twinax Copper |
|
| 机壳 | ||
| 7318 |
2BFB/46K7505/ 74Y7445 |
System backplane. |
| 7840 | Side-by-Side for 1.8m Racks | |
| 其它 | ||
|
2BCD/74Y5481/ 74Y3964 |
Control panel assembly | |
| 59Y4822 | Cable management arm assembly | |
| 74Y6301 | Fan cage assembly | |
| 74Y6714 | Interlock switch with cable | |
| 1103 | 46C5370/46C5380 |
USB Internal Docking Station for Removable Disk Drive |
| 1104 |
39M5516/44E8889/ 44V3429/46C5381/ 46C5394/49Y9890 |
USB External Docking Station for Removable Disk Drive |
| 1106 | 46C5374/46C5375 | USB 160 GB Removable Disk Drive |
| 1107 | 46C5379/46C5395 | USB 500 GB Removable Disk Drive |
| 1108 |
04N2351/04N2567/ 09L2576/09L2577/ 09L5276/09L5277/ 39J5596/45E0670/ 53P2650/95P1868/ 95P1869 |
Juniper EXP4200 Ethernet Switch |
| 1109 | IBM Ethernet Switch J48E | |
| 1114 |
Smart Analytics System routing indicator |
|
| 1135 | Integrated Storage Controller | |
| 1140 |
Custom Service Specify, Rochester Minn, USA |
|
| 1145 |
Juniper EXP4500 10 Gb Ethernet Switch |
|
| 1151 | Juniper EX4500 Ethernet Switch | |
| 1406 |
14F1553/39M5279/ 39Y5565/40K9772 |
200V 16A 4.3m (14-Ft) TL Line Cord |
| 1413 | 125V 4.3m (14-Ft) Line Cord | |
| 1414 |
39M5115/41V1961/ 86G7878 |
200V 6-Ft Locking Line Cord |
| 1415 | 41V1966/73F4931 |
200V 1.8m (6-Ft) Watertight Line Cord |
| 1416 | 200V 14-Ft Locking Line Cord | |
| 1417 |
200V 4.3m (14-Ft) Watertight Line Cord |
|
| 1418 |
14F1557/39M5291/ 40K9770 |
4.3m 200V/16A Power Cord S. Africa |
| 1419 |
14F1561/39M5311/ 40K9771 |
4.3m 200V/16A Power Cord Israel |
| 1420 |
14F1554/39M5383/ 40K9766 |
4.3m 200V/16A Power Cord EU/Asia |
| 1421 |
14F1555/36L8823 /39M5323/40K9769 |
4.3m 200V/16A Power Cord CH/DK |
| 1424 |
11F0114/11F0117/ 11F0117/41V2004 |
200V 6-Ft Locking Line Cord |
| 1425 |
07H6891/23R3230/ 46F4593 |
200V 6-Ft Wtrtght Line Cord |
| 1426 |
11F0113/11F0115/ 41V2003 |
200V 14-Ft Locking Line Cord |
| 1427 | 23R3231/46F4594 | 200V 14-Ft Wtrtght Line Cord |
| 1439 | 13F99809/39M5124 | 4.3m 200V/10A Power Cord EU/Asia |
| 1440 | 13F9998/39M5131 | 4.3m 200V/10A Pwr Cd Denmark |
| 1441 | 14F0016/39M5145 | 4.3m 200V/10A Pwr Cd S Afric |
| 1442 | 14F0052/39M5159 | 4.3m 200V/10A Pwr Cd Swiss |
| 1443 | 14F0034/39M5152 | 4.3m 200V/10A Pwr Cd UK |
| 1449 | 21H7693 | 4.3m 200V/32A Power Cord EU 1-PH |
| 1450 | 21H7691 | 4.3m 200V/16A Pwr Cd EU 2-PH |
| 1451 | 14F1547/39M5261 | 200V (6-Ft) 1.8m Line Cord |
| 1452 | 14F1548/39M5263 | 200V 14-Ft Line Cord |
| 1453 | 14F1549/39M5273 | 200V 6-Ft Locking Line Cord |
| 1454 | 14F1550/39M5275 | 200V 12A 14-Ft TL Line Cord |
| 1455 |
14F1551/39M5313/ 86F2645 |
200V 6-Ft Wtrtght Line Cord |
| 1456 |
14F1552/39M5315/ 86F2646 |
200V (14-Ft) 4.3m Watertight Line Cord |
| 1457 | 12J5120/39M5262 | 200V 6-Ft (1.8mUpper Line Cord |
| 1458 | 12J5119/39M5274 | 200V 6-Ft (1.8mUpper Locking Cord |
| 1459 | 93M5314/55H6644 | 200V 6-Ft Upper Wtrtght Cord |
| 1476 |
12J5988/39M5295/ 40K9767 |
4.3m/200V/12A Pwr Cd UK |
| 1477 | 4.3m 200V/16A Pwr Cd | |
| 2145 | 21H8079 | Primary OS - IBM i |
| 2146 | 44H6111 | Primary OS - AIX |
| 2147 | Primary OS - Linux | |
| 3632 | Widescreen LCD Monitor | |
| 3637 |
04N7526/04N7527/ 04N7532/13F9959/ 31P7507/31P7509/ 31P7511/31P7513/ 31P7515 |
IBM T541H /L150p 15" TFT Color Monitor |
| 3639 |
13F9959/31P9575/ 31P9577/31P9584/ 31P9587/31P9590/ 73P0261 |
L180P TFT 17" Color Display |
| 3640 | L171P TFT 17" Black Display | |
| 3641 |
40K7317/40K5341/ 73P4360 |
T115 TFT 15" Color Display |
| 3642 |
ThinkVision L191p Flat Panel Monitor |
|
| 3644 | IBM T119 Flat Panel Monitor | |
| 3645 | 39Y9919/40k5342 | IBM T117 Flat Panel Monitor |
| 4276 |
04N7533/09N3435 /25R9043 |
VGA to DVI Connection Converter |
| 4650 |
Rack Indicator-Not Factory Integrated |
|
| 4651 | Rack Indicator, Rack #1 | |
| 4660 | Rack Indicator, Rack #10 | |
| 4661 | Rack Indicator, Rack #11 | |
| 4662 | Rack Indicator, Rack #12 | |
| 4663 | Rack Indicator, Rack #13 | |
| 4664 | Rack Indicator, Rack #14 | |
| 4665 | Rack Indicator, Rack #15 | |
| 4666 | Rack Indicator, Rack #16 | |
| 4972 | Power 740 Solution Edition for IBM i | |
| 5000 | Software Preload Required | |
| 5002 |
07H9163/07H9163/ 31H3140/31H3140 |
AS/400 CDSC - Rochester Mfg |
| 5225 | 08L6201/08L6239 | PowerVM Express Edition |
| 5227 | PowerVM Standard Edition | |
| 5228 | 50G0947 | PowerVM Enterprise Edition |
| 5524 |
RFID TAGS FOR SERVERS, BLADES, BLADECENTERS, RACKS, AND HMCS |
|
| 5550 | Sys Console On HMC | |
| 5553 | Sys Console-Ethernet No IOP | |
| 5685 | PCIe Riser Card (Gen2) | |
| 5786 | TotalStorage EXP24 Disk Dwr | |
| 5787 | TotalStorage EXP24 Disk Twr | |
| 5796 | PCI-DDR 12X Expansion Drawer | |
| 5802 | 12X I/O Drawer PCIe, SFF disk | |
| 5877 | 12X I/O Drawer PCIe, No Disk | |
| 5886 | EXP 12S Expansion Drawer | |
| 5887 | EXP24S SFF Gen2-bay Drawer | |
| 5959 |
Full Width Quiet Touch Keyboard -- USB, Hungarian, #208 |
|
| 5983 | USB Keybd-US English Euro | |
| 6068 | Opt Front Door for 1.8m Rack | |
| 6069 | Opt Front Door for 2.0m Rack | |
| 6248 | 12R8349/44V0103 | 1.8m Rack Acoustic Doors |
| 6249 | 2.0m Rack Acoustic Doors | |
| 6263 | 1.8m Rack Trim Kit | |
| 6272 | 2.0m Rack Trim Kit | |
| 6492 | 4.3m (14-Ft) 1PH/48-60A Pwr Cord | |
| 6577 |
Power Cable - Drawer to IBM PDU, 200-240V/10A |
|
| 6580 | 41V0489 | Optional Rack Security Kit |
| 7118 | Environmental Monitoring Probe | |
| 7204 | Quantity 150 of #2124 | |
| 7205 | Quantity 150 of #2125 | |
| 7206 | Quantity 150 of #2126 | |
| 7207 | Quantity 150 of #2127 | |
| 7208 | Quantity 150 of #2128 | |
| 7213 | Quantity 150 of #2138 | |
| 7305 | SDI Software Pre-Install Indicator | |
| 7311 | Dual I/O Unit Enclosure | |
| 7314 | Dual 5796 Unit Enclosure | |
| 7572 | IBM Tower Cover Set (With door) | |
| 7573 | OEM Tower Cover Set (With door) | |
| 7780 | 2.0m Rack Side Attach Kit | |
| 8143 | Linux Software Preinstall | |
| 8144 | Linux Software Preinstall (SDIs) | |
| 9300 | Language Group Specify - US English | |
| 9359 | specify mode-1 1(1)5901/5278 for EXP24S #5887 | |
| 9360 | Specify mode-1 1(2)5901/5278 for EXP24S #5887 | |
| 9361 | Specify mode-2 1(2)5901/5278 for EXP24S #5887 | |
| 9365 |
Specify mode-4 1(4)5901/5278 for EXP24S #5887 |
|
| 9366 |
-Specify mode-2 1(4)5901/5278 for EXP24S #5887 |
|
| 9367 |
-Specify mode-1 1(2)5903/5805 for EXP24S #5887 |
|
| 9368 |
Specify mode-2 1(4)5903/5805 for EXP24S #5887 |
|
| 9382 |
Specify mode-1 1(1)5904/6/8 for EXP24S #5887 |
|
| 9383 |
Specify mode-1 1(2) 5904/6/8 for EXP24S #5887 |
|
| 9384 |
Specify mode-1 & CEC SAS port for EXP24 #5887 |
|
| 9440 | New AIX License Core Counter | |
| 9441 | New IBM i License Core Counter | |
| 9442 | New Red Hat License Core Counter | |
| 9443 | New SUSE License Core Counter | |
| 9444 | Other AIX License Core Counter | |
| 9445 | Other Linux License Core Counter | |
| 9446 | 3rd Party Linux Core Counter | |
| 9447 | VIOS Core Counter | |
| 9461 | Month Indicator | |
| 9462 | Day Indicator | |
| 9463 | Hour Indicator | |
| 9464 | Minute Indicator | |
| 9465 | Qty Indicator | |
| 9466 | Countable Member Indicator | |
| ELPM | Trial PowerVM Live Partition Mobility | |
